Optimizing SATisfiability-Based Automatic Test Pattern Generation Systems: Unified Fault Set Construction,Modeling, and Solving

YAN Dapeng; HE Qirun; GUO Jing; WANG Boning; CAI Zhikuang

doi:10.11999/JEIT260025

Article Contents

Article Navigation > Journal of Electronics & Information Technology > 2025 >

YAN Dapeng, HE Qirun, GUO Jing, WANG Boning, CAI Zhikuang. Optimizing SATisfiability-Based Automatic Test Pattern Generation Systems: Unified Fault Set Construction,Modeling, and Solving[J]. Journal of Electronics & Information Technology. doi: 10.11999/JEIT260025

Citation:

YAN Dapeng, HE Qirun, GUO Jing, WANG Boning, CAI Zhikuang. Optimizing SATisfiability-Based Automatic Test Pattern Generation Systems: Unified Fault Set Construction,Modeling, and Solving[J]. Journal of Electronics & Information Technology. doi: 10.11999/JEIT260025

Citation:

YAN Dapeng, HE Qirun, GUO Jing, WANG Boning, CAI Zhikuang. Optimizing SATisfiability-Based Automatic Test Pattern Generation Systems: Unified Fault Set Construction,Modeling, and Solving[J]. Journal of Electronics & Information Technology. doi: 10.11999/JEIT260025

PDF( 2002 KB)

Optimizing SATisfiability-Based Automatic Test Pattern Generation Systems: Unified Fault Set Construction,Modeling, and Solving

doi: 10.11999/JEIT260025 cstr: 32379.14.JEIT260025

1.
School of Integrated Circuit Science and Engineering, Nanjing University of Posts and Telecommunications, Nanjing 210023, China
2.
National and Local Joint Engineering Laboratory for RF Integration and Micro-Assembly Technology, Nanjing 210023, China

Received Date: 2026-01-08
Accepted Date: 2026-03-24
Rev Recd Date: 2026-03-18

Available Online: 2026-04-19

Abstract

Abstract

Objective Boolean SATisfiability-Based Automatic Test Pattern Generation (SAT-Based ATPG) is widely used to generate tests for hard-to-detect single stuck-at faults and to prove fault untestability in combinational logic. When SAT-Based ATPG is applied to large netlists with dense fanout and reconvergence, its runtime and memory consumption are often dominated by three interacting issues. Representative fault lists produced by conventional dominance- or equivalence-based fault collapsing can remain large, increasing the number of SAT calls and enlarging the incremental context that must be maintained across faults. Meanwhile, SAT modeling may introduce redundant Conjunctive Normal Form (CNF) overhead, especially when an explicit faulty-circuit copy is constructed or when propagation constraints are encoded globally without locality control. In addition, fanout-reconvergence structures amplify assignment correlations along sensitized paths, and such correlations are often exposed only after repeated decisions and backtracking when only standard unit propagation is used. The unified optimization objective is therefore to reduce overall CNF size and solving cost while preserving completeness, so that a practical SAT-Based ATPG system remains efficient and stable across circuits of different scales. Methods A three-part framework is developed and implemented in an incremental SAT-Based ATPG flow, and the overall workflow is illustrated (Fig. 1). First, a checkpoint-driven dynamic fault-set construction method is proposed. Checkpoints are collected during netlist-to-directed-acyclic-graph conversion, including all primary inputs and all fanout branches, and XOR/XNOR outputs are additionally recorded as supplementary checkpoints to avoid over-collapsing XOR-related fault behavior. Representative faults are initialized on checkpoints by compact rules that combine dominance-oriented fault collapsing with equivalence-aware refinement, and solver-guided repair is performed when an untestable representative fault indicates potential masking under structural constraints. The procedure is summarized in Algorithm 1. Second, a SAT modeling method based on fault sensitization constraints is adopted to avoid explicit faulty-circuit duplication. Fault activation, propagation, and observability are represented by additional fault sensitization constraints over the original circuit variables, and auxiliary variables are introduced only when local bookkeeping is required. Constraint localization is restricted to the fault fanout cone, and cone-boundary and internal vertices are identified through a graph-traversal procedure (Fig. 2). Third, a dynamic implication learning mechanism oriented to fanout-reconvergence pairs is integrated into the incremental solving loop. Reconvergence pairs within the fault fanout cone are monitored under partial assignments, and structure-induced implications are injected either as implied assignments when a reconvergent output becomes functionally determined or as short conflict clauses when a branch-value combination becomes inconsistent with the fault sensitization constraints. The dynamic implication learning procedure is summarized in Algorithm 2. Results and Discussions The unified system is evaluated on ISCAS’85 and ISCAS’89 benchmark circuits, with TG-PRO used as the baseline implementation under the same SAT solver and termination settings. The checkpoint-driven dynamic fault-set construction method substantially reduces the representative fault space entering ATPG. Relative to the uncollapsed fault space, the average representative-fault ratio decreases from 51.38% to 42.01%, corresponding to an average fault-space reduction of 57.99%. The best-case ratio reaches 33.19% on large circuits with heavy reconvergence, which indicates that checkpoint-centered representative-fault allocation effectively suppresses redundancy without enlarging the untestable fault set (Table 1). The reduced fault-set size is reflected in preprocessing efficiency, and the total runtime for fault-set construction is consistently reduced, with an average reduction of 8.37% across the evaluated circuits (Fig. 3). For SAT model construction, the fault-sensitization-constraint encoding reduces CNF overhead relative to the baseline model construction. Across the benchmark set, the numbers of CNF clauses and CNF variables are reduced by 11.44% and 3.50%, respectively, which shows that avoiding explicit faulty-circuit duplication and localizing auxiliary constraints to the fault fanout cone effectively lowers memory demand (Table 2). The reduced CNF size and strengthened locality of constraints are further reflected in end-to-end runtime, and the total runtime of SAT modeling and solving is reduced across the evaluated benchmarks (Fig. 4). Dynamic implication learning further improves solving efficiency in reconvergence-heavy structures. Compared with static implication learning, CNF construction time increases by 3.0% on average because of the additional monitoring and injection operations, yet the overall runtime decreases by 4.42% on average, which indicates a favorable cost-benefit trade-off. The overhead attributed to dynamic implication learning accounts for 2.51% of the total runtime aggregated across circuits, which confirms that the injected implications and pruning clauses provide measurable solving benefits at limited extra cost (Table 3). Conclusions A unified optimization framework for SAT-Based ATPG is developed by combining checkpoint-driven dynamic fault-set construction, localized fault sensitization constraints for CNF modeling, and fanout-reconvergence-oriented dynamic implication learning. Representative faults are compressed through solver-guided repair of dominance and equivalence relations to avoid masking, CNF growth is controlled through duplication-free modeling localized to the fault fanout cone, and reconvergence correlations are exploited through incremental implication injection to strengthen propagation and enable early conflict pruning. Experimental results on standard benchmark circuits show consistent reductions in representative fault scale, CNF size, and total runtime, providing a practical approach for scaling SAT-Based ATPG to larger designs with complex fanout and reconvergence.
- Automatic test pattern generation,
- Boolean satisfiability,
- Fault collapsing,
- Fault sensitization constraints,
- Dynamic implication learning
