Low-orbit Bistatic Frequency Modulated Continuous Wave SAR Imaging Method Based on Singular Value Decomposition

BIE Bowen; LIU Jiang; SUN Guangcai; WANG Di; XING Mengdao

doi:10.11999/JEIT220757

Volume 45 Issue 7

Jul. 2023

Turn off MathJax

Article Contents

Article Navigation > Journal of Electronics & Information Technology > 2023 > 45(7): 2502-2510

BIE Bowen, LIU Jiang, SUN Guangcai, WANG Di, XING Mengdao. Low-orbit Bistatic Frequency Modulated Continuous Wave SAR Imaging Method Based on Singular Value Decomposition[J]. Journal of Electronics & Information Technology, 2023, 45(7): 2502-2510. doi: 10.11999/JEIT220757

Citation:

BIE Bowen, LIU Jiang, SUN Guangcai, WANG Di, XING Mengdao. Low-orbit Bistatic Frequency Modulated Continuous Wave SAR Imaging Method Based on Singular Value Decomposition[J]. Journal of Electronics & Information Technology, 2023, 45(7): 2502-2510. doi: 10.11999/JEIT220757

Citation:

BIE Bowen, LIU Jiang, SUN Guangcai, WANG Di, XING Mengdao. Low-orbit Bistatic Frequency Modulated Continuous Wave SAR Imaging Method Based on Singular Value Decomposition[J]. Journal of Electronics & Information Technology, 2023, 45(7): 2502-2510. doi: 10.11999/JEIT220757

PDF( 7774 KB)

Low-orbit Bistatic Frequency Modulated Continuous Wave SAR Imaging Method Based on Singular Value Decomposition

doi: 10.11999/JEIT220757

1.
School of Electronic Engineering, Xidian University, Xi’an 710071, China
2.
National Key Laboratory of Radar Signal Processing, Xidian University, Xi’an 710071, China

Funds: The National Natural Science Foundation Youth Project of China (62001353)

Received Date: 2022-06-13
Rev Recd Date: 2022-10-20

Available Online: 2022-10-25

Publish Date: 2023-07-10

Abstract

Abstract

The imaging method of low-orbit bistatic SAR based on Frequency Modulated Continuous Wave (FMCW) signal is studied in this paper. The spaceborne bistatic model has the feature of transceiver separation and flexible structure. The nonlinear motion trajectory and bistatic slant range history are not conducive to the derivation and analysis of signal spectrum. The signal is constructed by a fourth-order polynomial slant range model. The expression of the two-dimensional spectrum of the signal is obtained by the method of series reversion. The spatial variation effect of the high-order polynomial coefficients is analyzed in detail. The range migration term is compensated in frequency domain. The azimuth phase is processed by the Singular Value Decomposition (SVD) method. Then the azimuth spectrum is divided into Doppler focusing terms and azimuth variation terms. A nonlinear azimuth scaling function is introduced. The azimuth variation can be completely corrected by two consecutive interpolations and resampling. The validity of the proposed method is verified by the simulation experiments.
- Low-orbit bistatic SAR,
- Frequency Modulated Continuous Wave (FMCW),
- Two-dimension spatial variation,
- Singular Value Decomposition (SVD)

FullText(HTML)

References(21)
