Two-segment Continuous Alignment and Error Analysis Method Based on Dual Antenna Assistance

Juhua YANG; Linjing ZHANG; Guangwu CHEN; Jianhao CHENG; Peng LI

doi:10.11999/JEIT191021

Volume 43 Issue 2

Feb. 2021

Turn off MathJax

Article Contents

Article Navigation > Journal of Electronics & Information Technology > 2021 > 43(2): 501-508

Juhua YANG, Linjing ZHANG, Guangwu CHEN, Jianhao CHENG, Peng LI. Two-segment Continuous Alignment and Error Analysis Method Based on Dual Antenna Assistance[J]. Journal of Electronics & Information Technology, 2021, 43(2): 501-508. doi: 10.11999/JEIT191021

Citation:

Juhua YANG, Linjing ZHANG, Guangwu CHEN, Jianhao CHENG, Peng LI. Two-segment Continuous Alignment and Error Analysis Method Based on Dual Antenna Assistance[J]. Journal of Electronics & Information Technology, 2021, 43(2): 501-508. doi: 10.11999/JEIT191021

Citation:

PDF( 1583 KB)

Two-segment Continuous Alignment and Error Analysis Method Based on Dual Antenna Assistance

doi: 10.11999/JEIT191021

Juhua YANG³,
Linjing ZHANG^{1, 2
,
,},
Guangwu CHEN^{1, 2},
Jianhao CHENG^{1, 2},
Peng LI^{1, 2}

1.
Institute of Automatic Control, Lanzhou Jiaotong University, Lanzhou 730070, China
2.
Key Laboratory of Plateau Traffic Information Engineering and Control of Gansu Province, Lanzhou 730070, China
3.
School of Traffic and Transportation, Lanzhou Jiaotong University, Lanzhou 730070, China

Funds: The National Natural Science Foundation of China (61863024, 71761023), Gansu Provincial University Research Project Funding (2018C-11, 2018A-22), The Natural Science Foundation of Gansu Province (18JR3RA130, 18JR3RA110)

Received Date: 2019-12-23
Rev Recd Date: 2020-09-13

Available Online: 2020-09-28

Publish Date: 2021-02-23

Abstract

Abstract

Considering the problem that it is difficult to obtain the initial position accurately in the low-precision Inertial Measurement Unit/Global Navigation Satellite System (IMU/GNSS) loose integrated navigation system and the course divergence is easy to travel. A two-segment continuous alignment method assisted by dual antennas is designed. Firstly, the influence of initial bearing error on heading accuracy is analyzed. Secondly, due to the characteristics of high accuracy and poor dynamic response of the GNSS direction-finding system, a least-squares attitude estimation model is derived based on the dual-antenna baseline vector for initial alignment. Finally, for the alignment between travels, the research extendes the one-dimensional measurement based on the heading difference to suppress the heading error. The design experiment explores the influence of the dual antenna baseline vector on the initial alignment and the heading accuracy between travels. The improved method can make the initial azimuth error better than 0.7°. At the same time, the heading angle between travels can be tracked more accurately. For the initial alignment of the target and the alignment between the traveling, the dual antenna can provide auxiliary information, its effect is better than the single antenna IMU/GNSS combination, and the method calculation is moderate.
- Dual antenna,
- Alignment,
- Baseline

FullText(HTML)

References(14)

References

李杨, 孙伟强, 王兴岭, 等. 空间不一致在动态对准中影响分析及补偿方法[J]. 中国惯性技术学报, 2018, 26(5): 567–570. doi: 10.13695/j.cnki.12-1222/o3.2018.05.002

LI Yang, SUN Weiqiang, WANG Xingling, et al. Influence of space inconsistencyon in-motion alignment and compensation method for large ship[J]. Journal of Chinese Inertial Technology, 2018, 26(5): 567–570. doi: 10.13695/j.cnki.12-1222/o3.2018.05.002

HAO Yushi, XU Aigong, SUI Xin, et al. A modified extended Kalman filter for a two-antenna GPS/INS vehicular navigation system[J]. Sensors, 2018, 18(11): 3809. doi: 10.3390/s18113809

ISMAIL M and ABDELKAWY E. A hybrid error modeling for MEMS IMU in integrated GPS/INS navigation system[J]. The Journal of Global Positioning Systems, 2018, 16(1): 6. doi: 10.1186/s41445-018-0016-5

KHALAF W, CHOUAIB I, and WAINAKH M. Novel adaptive UKF for tightly-coupled INS/GPS integration with experimental validation on an UAV[J]. Gyroscopy and Navigation, 2017, 8(4): 259–269. doi: 10.1134/S2075108717040083

陈光武, 程鉴皓, 杨菊花, 等. 基于改进神经网络增强自适应UKF的组合导航系统[J]. 电子与信息学报, 2019, 41(7): 1766–1773. doi: 10.11999/JEIT181171

CHEN Guangwu, CHENG Jianhao, YANG Juhua, et al. Improved neural network enhanced navigation system of adaptive UKF[J]. Journal of Electronics &Information Technology, 2019, 41(7): 1766–1773. doi: 10.11999/JEIT181171

庞春雷, 赵修斌, 余永林, 等. 低精度SINS初始对准/GPS双天线测向互辅算法[J]. 西安电子科技大学学报: 自然科学版, 2014, 41(6): 167–173. doi: 10.3969/j.issn.1001-2400.2014.06.028

PANG Chunlei, ZHAO Xiubin, YU Yonglin, et al. Interact arithmetic of low-accuracy SINS’initial alignment and GPS orientation measurement with two antennas[J]. Journal of Xidian University:Natural Science, 2014, 41(6): 167–173. doi: 10.3969/j.issn.1001-2400.2014.06.028

张方照, 柴艳菊, 柴华, 等. 两种多天线GNSS定姿方法的精度分析[J]. 中国惯性技术学报, 2016, 24(1): 30–35. doi: 10.13695/j.cnki.12-1222/o3.2016.01.007

ZHANG Fangzhao, CHAI Yanju, CHAI Hua, et al. Analysis on precision of two attitude determination methods using GNSS multi-antenna data[J]. Journal of Chinese Inertial Technology, 2016, 24(1): 30–35. doi: 10.13695/j.cnki.12-1222/o3.2016.01.007

蔡体菁, 陈仁, 王鑫, 等. 北斗短基线双天线旋转快速定向方法[J]. 中国惯性技术学报, 2018, 26(3): 305–309. doi: 10.13695/j.cnki.12-1222/o3.2018.03.005

CAI Tijing, CHEN Ren, WANG Xin, et al. Fast orientation method by BeiDou short baseline dual-antennas rotation[J]. Journal of Chinese Inertial Technology, 2018, 26(3): 305–309. doi: 10.13695/j.cnki.12-1222/o3.2018.03.005

LI Wanli, TANG Kanghua, LU Liangqing, et al. Optimization-based INS in-motion alignment approach for underwater vehicles[J]. Optik, 2013, 124(20): 4581–4585. doi: 10.1016/j.ijleo.2013.01.069

KANG Taizhong, FANG Jiancheng, and WANG Wei. Quaternion-optimization-based in-flight alignment approach for airborne POS[J]. IEEE Transactions on Instrumentation and Measurement, 2012, 61(11): 2916–2923. doi: 10.1109/TIM.2012.2202989

EMEL’YANTSEV G I, STEPANOV A P, and BLAZHNOV B A. Attitude determination by INS/GNSS system aided by phase and magnetometer measurements for spinning vehicles[J]. Gyroscopy and Navigation, 2014, 5(4): 205–212. doi: 10.1134/S207510871404004X

周广涛, 王晴晴, 高远. 基于ZIHR航向角修正方法的行人导航算法[J]. 系统工程与电子技术, 2019, 41(1): 170–177. doi: 10.3969/j.issn.1001-506X.2019.01.24

ZHOU Guangtao, WANG Qingqing, and GAO Yuan. Pedestrian navigation algorithm based on ZIHR heading angle correction method[J]. Systems Engineering and Electronics, 2019, 41(1): 170–177. doi: 10.3969/j.issn.1001-506X.2019.01.24

何东旭, 葛磊, 张鑫, 等. 罗经方位对准的收敛时间分析[J]. 中国舰船研究, 2019, 14(5): 159–166. doi: 10.19693/j.issn.1673-3185.01522

HE Dongxu, GE Lei, ZHANG Xin, et al. Analysis on convergence time of gyrocompass azimuth alignment[J]. Chinese Journal of Ship Research, 2019, 14(5): 159–166. doi: 10.19693/j.issn.1673-3185.01522

李杰, 杨雁宇, 冯凯强, 等. 一种融合互补滤波和卡尔曼滤波高精度姿态测量算法[J]. 中国惯性技术学报, 2018, 26(1): 51–55, 86. doi: 10.13695/j.cnki.12-1222/o3.2018.01.009

LI Jie, YANG Yanyu, FENG Kaiqiang, et al. High-precision attitude measurement algorithm based on complementary filtering and Kalman filtering[J]. Journal of Chinese Inertial Technology, 2018, 26(1): 51–55, 86. doi: 10.13695/j.cnki.12-1222/o3.2018.01.009
