NAND Gate Computational Model Based on the DNA Origami Template

Zhixiang YIN; Zhen TANG; Qiang ZHANG; Jianhong CUI; Jing YANG; Risheng WANG; Shouwei ZHAO; Juli ZHANG

doi:10.11999/JEIT190825

Volume 42 Issue 6

Jun. 2020

Turn off MathJax

Article Contents

Article Navigation > Journal of Electronics & Information Technology > 2020 > 42(6): 1355-1364

Zhixiang YIN, Zhen TANG, Qiang ZHANG, Jianhong CUI, Jing YANG, Risheng WANG, Shouwei ZHAO, Juli ZHANG. NAND Gate Computational Model Based on the DNA Origami Template[J]. Journal of Electronics & Information Technology, 2020, 42(6): 1355-1364. doi: 10.11999/JEIT190825

Citation:

Zhixiang YIN, Zhen TANG, Qiang ZHANG, Jianhong CUI, Jing YANG, Risheng WANG, Shouwei ZHAO, Juli ZHANG. NAND Gate Computational Model Based on the DNA Origami Template[J]. Journal of Electronics & Information Technology, 2020, 42(6): 1355-1364. doi: 10.11999/JEIT190825

Citation:

PDF( 5225 KB)

NAND Gate Computational Model Based on the DNA Origami Template

doi: 10.11999/JEIT190825

1.
School of Mathematics, Physics and Statistics, Shanghai University of Engineering Science, Shanghai 201620, China
2.
School of Mathematics and Big Data, Anhui University of Science and Technology, Huainan 232001, China
3.
School of Computer Science and Technology, Dalian University of Technology, Dalian 116024, China
4.
Department of Computer, Huainan Union University, Huainan 232001, China

Funds: The National Natural Science Foundation of China (61672001, 61702008, 11801362), The Natural Science Foundation of Anhui Province (1808085MF193), The Natural Science Research Project of Universities in Anhui Province (KJ2019A0538)

Received Date: 2019-10-28
Rev Recd Date: 2020-01-17

Available Online: 2020-02-19

Publish Date: 2020-06-22

Abstract

Abstract

The essence of NAND gate is the superposition of AND gate and NOT gate. The AND gate operation is performed first, and then the NOT gate is performed. It is the basis of the DNA computer. In order to realize the computing of NAND gate, a NAND gate computational model is established based on the DNA origami template. The inputs of the logic value are completed by the Hybridization Chain Reaction (HCR) on the DNA origami template. The input strands first react with the AND gate region and then react with the NOT gate region. The result of the reaction is shown by dynamically separation of the gold nanoparticles on the DNA origami template. The simulation of the model through Visual DSD shows that the system has the advantages of high feasibility.
