Joint User Association and Power Allocation Algorithm for Network Slicing Based on NOMA

Lun TANG; Runlin MA; Heng YANG; Qianbin CHEN

doi:10.11999/JEIT180770

Volume 41 Issue 9

Sep. 2019

Turn off MathJax

Article Contents

Article Navigation > Journal of Electronics & Information Technology > 2019 > 41(9): 2039-2046

Lun TANG, Runlin MA, Heng YANG, Qianbin CHEN. Joint User Association and Power Allocation Algorithm for Network Slicing Based on NOMA[J]. Journal of Electronics & Information Technology, 2019, 41(9): 2039-2046. doi: 10.11999/JEIT180770

Citation:

Lun TANG, Runlin MA, Heng YANG, Qianbin CHEN. Joint User Association and Power Allocation Algorithm for Network Slicing Based on NOMA[J]. Journal of Electronics & Information Technology, 2019, 41(9): 2039-2046. doi: 10.11999/JEIT180770

Citation:

PDF( 2423 KB)

Joint User Association and Power Allocation Algorithm for Network Slicing Based on NOMA

doi: 10.11999/JEIT180770

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Key Laboratory of Mobile Communication Technology, Chongqing University of Post and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61571073), The Science and Technology Research Program of Chongqing Municipal Education Commission (KJZD-M201800601)

Received Date: 2018-08-23
Rev Recd Date: 2019-03-20

Available Online: 2019-05-30

Publish Date: 2019-09-10

Abstract

Abstract

To satisfy the diversity of requirements for different network slices and realize dynamic allocation of wireless virtual resource, an algorithm for network slice joint user association and power allocation is proposed in Non-Orthogonal Multiple Access(NOMA) C-RAN. Firstly, by considering imperfect Channel State Information(CSI), a joint user association and power allocation algorithm is designed to maximize the average total throughput in C-RAN with the constraints of slice and user minimum required rate, outage probability and fronthaul capacity limits. Secondly, a joint user association and power allocation algorithm is designed according to the current slot by transforming the probabilistic mixed optimalization problem into a non-probabilistic optimalization problem and using Lyapunov optimization. Finally, for user association problem, a greedy algorithm is proposed to find a feasible suboptimal solution; The power allocation problem is transformed into a convex optimization problem by using successive convex approximation; Then a dual decomposition approach is exploited to obtain a power allocation strategy. Simulation results demonstrate that the proposed algorithm can effectively improve the average total throughput of system while guaranteeing the network slice and user requirement.
- Network slicing,
- Resource allocation,
- Imperfect Channel State Information (CSI),
- Non-Orthogonal Multiple Access (NOMA)

FullText(HTML)

References(13)

References

LIU Gang, YU F R, JI Hong, et al. Distributed resource allocation in virtualized full-duplex relaying networks[J]. IEEE Transactions on Vehicular Technology, 2016, 65(10): 8444–8460. doi: 10.1109/TVT.2015.2513070

YIN Lei, QIU Ling, and CHEN Zheng. Throughput-maximum resource provision in the OFDMA-based wireless virtual network[C]. IEEE 85th Vehicular Technology Conference (VTCSpring), Sydney, Australia, 2017: 1–6. doi: 10.1109/VTCSpring.2017.8108502.

SINAIE M, NG D W K, and JORSWIECK E A. Resource allocation in NOMA virtualized wireless networks under statistical delay constraints[J]. IEEE Wireless Communications Letters, 2018, 7(6): 954–957. doi: 10.1109/LWC.2018.2841852

DAWADI R, PARSAEEFARD S, DERAKHSHANI M, et al. Power-efficient resource allocation in NOMA virtualized wireless networks[C]. IEEE Global Communications Conference (GLOBECOM), Washington, USA, 2016: 1–6. doi: 10.1109/GLOCOM.2016.7842162.

LEE Y L, LOO J, CHUAH T C, et al. Dynamic network slicing for multitenant heterogeneous cloud radio access networks[J]. IEEE Transactions on Wireless Communications, 2018, 17(4): 2146–2161. doi: 10.1109/TWC.2017.2789294

HA V N and LE L B. End-to-end network slicing in virtualized OFDMA-based cloud radio access networks[J]. IEEE Access, 2017, 5: 18675–18691. doi: 10.1109/ACCESS.2017.2754461

IKKI S S and AISSA A. Two-way amplify-and-forward relaying with Gaussian imperfect channel estimations[J]. IEEE Communications Letters, 2012, 16(7): 956–959. doi: 10.1109/LCOMM.2012.050912.120103

WANG Xiaoming, ZHENG Fuchun, ZHU Pengcheng, et al. Energy-efficient resource allocation in coordinated downlink multicell OFDMA systems[J]. IEEE Transactions on Vehicular Technology, 2016, 65(3): 1395–1408. doi: 10.1109/TVT.2015.2413950

XIANG Xudong, LIN Chuang, CHEN Xin, et al. Toward optimal admission control and resource allocation for LTE-A femtocell uplink[J]. IEEE Transactions on Vehicular Technology, 2015, 64(7): 3247–3261. doi: 10.1109/TVT.2014.2351837

PAPANDRIOPOULOS J and EVANS J S. SCALE: A low-complexity distributed protocol for spectrum balancing in multiuser DSL networks[J]. IEEE Transactions on Information Theory, 2009, 55(8): 3711–3724. doi: 10.1109/TIT.2009.2023751

FOOLADIVANDA D and ROSENBERG C. Joint resource allocation and user association for heterogeneous wireless cellular networks[J]. IEEE Transactions on Wireless Communications, 2013, 12(1): 248–257. doi: 10.1109/TWC.2012.121112.120018

ZHU Jianyue, WANG Jiaheng, HUANG Yongming, et al. On optimal power allocation for downlink non-orthogonal multiple access systems[J]. IEEE Journal on Selected Areas in Communications, 2017, 35(12): 2744–2757. doi: 10.1109/JSAC.2017.2725618

PARIDA P and DAS S S. Power allocation in OFDM based NOMA systems: A DC programming approach[C]. IEEE GLOBECOM Workshops, Austin, USA, 2015: 1026–1031.
