面向多目标多用户的雷达通信一体化恒模波形设计

朱锦锟 金添 唐宇航 宋勇平 刘伟

朱锦锟, 金添, 唐宇航, 宋勇平, 刘伟. 面向多目标多用户的雷达通信一体化恒模波形设计[J]. 电子与信息学报, 2023, 45(11): 3821-3829. doi: 10.11999/JEIT230827
引用本文: 朱锦锟, 金添, 唐宇航, 宋勇平, 刘伟. 面向多目标多用户的雷达通信一体化恒模波形设计[J]. 电子与信息学报, 2023, 45(11): 3821-3829. doi: 10.11999/JEIT230827
ZHU Jinkun, JIN Tian, TANG Yuhang, SONG Yongping, LIU Wei. Multi-User and Multi-Target Constant Waveform Design of Dual-Function Radar and Communication System[J]. Journal of Electronics & Information Technology, 2023, 45(11): 3821-3829. doi: 10.11999/JEIT230827
Citation: ZHU Jinkun, JIN Tian, TANG Yuhang, SONG Yongping, LIU Wei. Multi-User and Multi-Target Constant Waveform Design of Dual-Function Radar and Communication System[J]. Journal of Electronics & Information Technology, 2023, 45(11): 3821-3829. doi: 10.11999/JEIT230827

面向多目标多用户的雷达通信一体化恒模波形设计

doi: 10.11999/JEIT230827
详细信息
    作者简介:

    朱锦锟:男,博士生,研究方向为雷达通信一体化

    金添:男,教授,研究方向为超宽带成像与目标识别

    唐宇航:男,硕士生,研究方向为雷达通信一体化

    宋勇平:男,讲师,研究方向为穿墙成像、雷达成像、雷达目标检测

    刘伟:男,副教授,研究方向为通信信号处理、5G/6G通信技术

    通讯作者:

    金添 tianjin@nudt.edu.cn

  • 中图分类号: TN959.1

Multi-User and Multi-Target Constant Waveform Design of Dual-Function Radar and Communication System

  • 摘要: 双功能雷达通信一体化系统可以使硬件和频谱资源得到有效利用,是解决当前无线频谱资源紧张问题的一种有效途径。该文针对同时多目标探测与多用户通信场景,以雷达接收回波的信干噪比(SINR)为指标保障雷达的探测性能,采用通信多用户干扰(MUI)作为通信指标保证通信传输性能。与此同时,为保证发射端功率放大器工作在饱和区域,增加了波形恒模的约束条件。该文通过对波形以及滤波器的联合优化,提出了一种在满足通信MUI功率一定的情况下,最大化雷达多目标探测回波最小信干噪比(SINR)的波形设计优化模型。针对此优化问题,采用了交替迭代优化的方法来求解此问题。仿真结果表明,所设计的波形在多目标探测以及多用户通信场景下,通过调整通信MUI功率门限,可以在保证通信MUI功率性能前提下,实现对多目标回波最小SINR的优化。
  • 图  1  双功能雷达通信系统模型示意图

    图  2  不同目标数量时算法实现的目标函数值随着迭代次数变化图

    图  3  发射波束图

    图  4  不同${\eta }$值下的SINR变化图

    算法1 求解问题(21)算法流程
     输入:初始化变量${{\boldsymbol{s}}^{(0)}}$, ${e^{(0)}}$, ${\beta ^{(0)}}$, ${\delta _s}$和$ {\delta _\beta } $。
     输出:问题式(38)的解$s$;
     第1步:$j = 0$;
     第2步:${{\boldsymbol{s}}^{(j - 1)}}{\text{ = }}{{\boldsymbol{s}}^{(0)}},\;{e^{(j - 1)}}{\text{ = }}{e^{(0)}}$;
     第3步:求解问题式(38)得到$ ({{\boldsymbol{s}}^{(j)}},{e^{(j)}},{\beta ^{(j)}}) $;
     第4步:若${\left\| {{\beta ^{(j)}}} \right\|_1} < \tau $,则输出$ {\boldsymbol{s}} = {{\boldsymbol{s}}^{(j)}} $,否则继续下一步
     第5步:${{\boldsymbol{s}}^{(0)}}{\text{ = }}{{\boldsymbol{s}}^{(j)}},\;{e^{(0)}}{\text{ = }}{e^{(j)}},\;j{\text{ = }}j + 1$返回第2步
    下载: 导出CSV
    算法2 交替迭代优化算法流程
     输入:初始化变量${s^{(0)}}$, ${e^{(0)}}$, ${\beta ^{(0)}}$, ${\delta _s}$, $ {\delta _\beta } $和$\kappa $。
     输出:问题式(16)的解${s^{(*)}}$,$\left\{ {{\boldsymbol{w}}_m^*} \right\}_{m = 1}^M$。
     第1步:$c = 0$,构$ {{\chi }_m}\left( {{{\boldsymbol{s}}^{(0)}}} \right) $, $ {{\boldsymbol{\varLambda}} _m}\left( {{{\boldsymbol{s}}^{(0)}}} \right) $;
     第2步:求解问题式(19)得到$\left\{ {{\boldsymbol{w}}_m^{(0)}} \right\}_{m = 1}^M$;
     第3步:$c = c + 1$;
     第4步:构造$ {{{\boldsymbol{\varOmega}} }_m}\left( {{\boldsymbol{w}}_m^{(c - 1)}} \right) $, $ {{\boldsymbol{\varGamma}}_m}\left( {{\boldsymbol{w}}_m^{(c - 1)}} \right) $,求解问题式(21)
     得到${{\boldsymbol{s}}^{(c)}}$;
     第5步:构造$ {{\chi }_m}\left( {{{\boldsymbol{s}}^{(c)}}} \right) $, $ {{\boldsymbol{\varLambda}} _m}\left( {{{\boldsymbol{s}}^{(c)}}} \right) $ ,求解问题式(19),得到
     $\left\{ {{\boldsymbol{w}}_m^{(c)}} \right\}_{m = 1}^M$
     第6步:计算${\min _{\forall m}}{\text{SIN}}{{\text{R}}_m}\left( {{\boldsymbol{s}},{{\boldsymbol{w}}_m}} \right)$
      若$ |\min _{_{\forall m}}^j{{{\mathrm{SINR}}} _m}\left( {{{\boldsymbol{s}}^{(c)}},{\boldsymbol{w}}_m^{(c)}} \right) - \min _{_{\forall m}}^{(c - 1)}{{{\mathrm{SINR}}} _m}$
      $\left( {{{\boldsymbol{s}}^{({c} - 1)}},{\boldsymbol{w}}_m^{(c - 1)}} \right)|{\text{ }} < {\text{ }}\kappa $,
      输出${s^{(*)}}$=${s^{(c)}}$, $\left\{ {{\boldsymbol{w}}_m^*} \right\}_{m = 1}^M = \left\{ {{\boldsymbol{w}}_m^{(c)}} \right\}_{m = 1}^M$,否则返回第3步。
    下载: 导出CSV
  • [1] LIU Rang, LI Ming, LIU Qian, et al. Dual-functional radar-communication waveform design: A symbol-level precoding approach[J]. IEEE Journal of Selected Topics in Signal Processing, 2021, 15(6): 1316–1331. doi: 10.1109/JSTSP.2021.3111438
    [2] LIU Fan, CUI Yuanhao, MASOUROS C, et al. Integrated sensing and communications: Toward dual-functional wireless networks for 6G and beyond[J]. IEEE Journal on Selected Areas in Communications, 2022, 40(6): 1728–1767. doi: 10.1109/JSAC.2022.3156632
    [3] KENNEY J B. Dedicated short-range communications (DSRC) standards in the United States[J]. Proceedings of the IEEE, 2011, 99(7): 1162–1182. doi: 10.1109/JPROC.2011.2132790
    [4] KUMARI P, CHOI J, GONZALEZ-PRELCIC N, et al. IEEE 802.11ad-based radar: An approach to joint vehicular communication-radar system[J]. IEEE Transactions on Vehicular Technology, 2018, 67(4): 3012–3027. doi: 10.1109/TVT.2017.2774762
    [5] WYMEERSCH H, SECO-GRANADOS G, DESTINO G, et al. 5G mmWave positioning for vehicular networks[J]. IEEE Wireless Communications, 2017, 24(6): 80–86. doi: 10.1109/MWC.2017.1600374
    [6] GROSSI E, LOPS M, VENTURINO L, et al. Opportunistic Radar in IEEE 802.11ad networks[J]. IEEE Transactions on Signal Processing, 2018, 66(9): 2441–2454. doi: 10.1109/TSP.2018.2813300
    [7] HAN Liang and WU Ke. Joint wireless communication and radar sensing systems – state of the art and future prospects[J]. IET Microwaves, Antennas & Propagation, 2013, 7(11): 876–885. doi: 10.1049/iet-map.2012.0450.
    [8] SHI Chenguang, WANG Fei, SELLATHURAI M, et al. Power minimization-based robust OFDM Radar waveform design for radar and communication systems in coexistence[J]. IEEE Transactions on Signal Processing, 2018, 66(5): 1316–1330. doi: 10.1109/TSP.2017.2770086
    [9] SADDIK G N, SINGH R S, and BROWN E R. Ultra-wideband multifunctional communications/radar system[J]. IEEE Transactions on Microwave Theory and Techniques, 2007, 55(7): 1431–1437. doi: 10.1109/TMTT.2007.900343
    [10] 杨慧婷, 周宇, 谷亚彬, 等. 参数调制多载波雷达通信共享信号设计[J]. 雷达学报, 2019, 8(1): 54–63. doi: 10.12000/JR18001

    YANG Huiting, ZHOU Yu, GU Yabin, et al. Design of integrated radar and communication signal based on multicarrier parameter modulation signal[J]. Journal of Radars, 2019, 8(1): 54–63. doi: 10.12000/JR18001
    [11] BHAT S S, NARAYANAN R M, and RANGASWAMY M. Bandwidth sharing and scan scheduling in multimodal radar with communications and tracking[J]. IETE Journal of Research, 2013, 59(5): 551–562. doi: 10.4103/0377-2063.123761
    [12] TEMIZ M, ALSUSA E, and BAIDAS M W. A dual-functional massive MIMO OFDM communication and radar transmitter architecture[J]. IEEE Transactions on Vehicular Technology, 2020, 69(12): 14974–14988. doi: 10.1109/TVT.2020.3031686
    [13] LIU Fan, MASOUROS C, LI Ang, et al. MU-MIMO communications with MIMO Radar: From Co-existence to joint transmission[J]. IEEE Transactions on Wireless Communications, 2018, 17(4): 2755–2770. doi: 10.1109/TWC.2018.2803045
    [14] MA Dingyou, SHLEZINGER N, HUANG Tianyao, et al. Spatial modulation for joint radar-communications systems: Design, analysis, and hardware prototype[J]. IEEE Transactions on Vehicular Technology, 2021, 70(3): 2283–2298. doi: 10.1109/TVT.2021.3056408
    [15] 石长安, 刘一民, 王希勤, 等. 基于帕累托最优的雷达-通信共享孔径研究[J]. 电子与信息学报, 2016, 38(9): 2351–2357. doi: 10.11999/JEIT151377

    SHI Chang’an, LIU Yimin, WANG Xiqin, et al. Optimal allocation of shared aperture in Radar-communication integrated system based on Pareto optimality[J]. Journal of Electronics & Information Technology, 2016, 38(9): 2351–2357. doi: 10.11999/JEIT151377
    [16] 单成兆, 马永奎, 赵洪林, 等. 基于时间调制阵列的多波束雷达通信一体化结构及算法研究[J]. 信号处理, 2020, 36(10): 1644–1653. doi: 10.16798/j.issn.1003-0530.2020.10.003

    SHAN Chengzhao, MA Yongkui, ZHAO Honglin, et al. Structure and algorithm of time-modulated array based multi-beam Radar-communications integration[J]. Journal of Signal Processing, 2020, 36(10): 1644–1653. doi: 10.16798/j.issn.1003-0530.2020.10.003
    [17] HASSANIEN A, AMIN M G, ZHANG Y D, et al. Dual-function radar-communications: Information embedding using sidelobe control and waveform diversity[J]. IEEE Transactions on Signal Processing, 2016, 64(8): 2168–2181. doi: 10.1109/TSP.2015.2505667
    [18] LIU Fan, ZHOU Longfei, MASOUROS C, et al. Toward dual-functional radar-communication systems: Optimal waveform design[J]. IEEE Transactions on Signal Processing, 2018, 66(16): 4264–4279. doi: 10.1109/TSP.2018.2847648
    [19] LIU Xiang, HUANG Tianyao, SHLEZINGER N, et al. Joint transmit beamforming for multiuser MIMO communications and MIMO Radar[J]. IEEE Transactions on Signal Processing, 2020, 68: 3929–3944. doi: 10.1109/TSP.2020.3004739
    [20] TIAN Tuanwei, ZHANG Tianxian, KONG Lingjiang, et al. Transmit/receive beamforming for MIMO-OFDM based dual-function radar and communication[J]. IEEE Transactions on Vehicular Technology, 2021, 70(5): 4693–4708. doi: 10.1109/TVT.2021.3072094
    [21] SHI Chenguang, WANG Yijie, WANG Fei, et al. Joint optimization scheme for subcarrier selection and power allocation in multicarrier dual-function radar-communication system[J]. IEEE Systems Journal, 2021, 15(1): 947–958. doi: 10.1109/JSYST.2020.2984637
    [22] ZHONG Kai, HU Jinfeng, PAN Cunhua, et al. Joint waveform and beamforming design for RIS-aided ISAC systems[J]. IEEE Signal Processing Letters, 2023, 30: 165–169. doi: 10.1109/LSP.2023.3242554
    [23] MOHAMMED S K and LARSSON E G. Per-antenna constant envelope precoding for large multi-user MIMO systems[J]. IEEE Transactions on Communications, 2013, 61(3): 1059–1071. doi: 10.1109/TCOMM.2013.012913.110827
    [24] YU Xianxiang, ALHUJAILI K, CUI Guolong, et al. MIMO Radar waveform design in the presence of multiple targets and practical constraints[J]. IEEE Transactions on Signal Processing, 2020, 68: 1974–1989. doi: 10.1109/TSP.2020.2979602
