一种基于开口谐振环的高增益宽带双极化天线设计

任宇辉; 丁君; 郭陈江

doi:10.11999/JEIT170111

一种基于开口谐振环的高增益宽带双极化天线设计

doi: 10.11999/JEIT170111

2.
(西北工业大学电子信息学院西安 710129) ②(西北大学信息科学与技术学院西安 710069)

基金项目:

西安爱生创新发展基金(ASN-IF2015-0901)

计量
- 文章访问数: 1926
- HTML全文浏览量: 281
- PDF下载量: 293
- 被引次数: 0
出版历程
- 收稿日期: 2017-02-10
- 修回日期: 2017-08-17
- 刊出日期: 2017-11-19

Design of a High-gain Wideband Dual-polarized Antenna Based on Split Ring Resonators

2.
(School of Electronics and Information, University of Northwestern Polytechnical, Xi&rsquo

Funds:

The Innovation Development Fund of Xi'an Aisheng Group (ASN-IF2015-0901)

摘要

摘要: 该文设计并制作了一种基于超材料的高增益宽带双极化天线，该天线由两个正交放置的印刷振子单元、馈电巴伦及金属接地板构成。为了进一步展宽带宽、提高增益，在天线上了加载开口谐振环、互补开口谐振环等超材料结构。测试结果表明，该天线回波损耗小于-10 dB的带宽约为69%(0.98~2.01 GHz)，在相同的频带内隔离度大于20 dB。由于开口谐振环的引向作用，天线的辐射特性得到改善，增益最大提高了4.1 dB左右。和已有设计相比，该天线的总体高度减小了约12%。其可以当作独立天线使用，也可用作反射面天线的双极化馈源。
- 开口谐振环 /
- 互补开口谐振环 /
- 双极化天线
Abstract: A wideband and high gain dual-polarized antenna based on split ring resonators is presented. The antenna is composed of two cross printed dipole antennas vertically fixed on an aluminum plate as ground plane, which are excited by two similar micro-strip baluns. In order to further improve the gain with a broad bandwidth, split ring resonators and complementary split ring resonators are loaded on the printed dipole antennas. Measured results show that the proposed antenna achieves -10 dB return loss with bandwidth of 0.98~2.01 GHz (69%), and its port isolation is higher than 20 dB within that band. The maximum gain of antenna is improved up by 4.1 dB because of split ring resonators. Furthermore, the height of the antenna is reduced about 12% than the LPPDs- DPA.
- Split ring resonators /
- Complementary split ring resonators /
- Dual-polarized antenna

HTML全文

参考文献(20)

CUI Guanfeng, ZHOU Shigang, ZHAO Gang, et al. A compact dual-polarized antenna for base station application [J]. Progress in Electromagnetics Research Letters, 2016, 59: 7-13. doi: 10.2528/PIERL16010804.

LI Z, CHEN L, ZHANG H, et al. Dual-polarized patch antenna with high isolation for DTV applications[J]. Journal of Electromagnetic Waves and Applications, 2013, 27(14): 1759-1766. doi: 10.1080/09205071.2013.823359.

SIMONE Z, GERARD Zamora, PAU A, et al. Analysis of the split ring resonator (SRR) Antenna applied to passive UHF- RFID tag design[J]. IEEE Transactions on Antennas and Propagation, 2016, 64(3): 856-864. doi: 10.1109/TAP.2015. 2513084.

GAO, Shichang, LI Lewei, LEONG M, et al. Dual-polarized slot-coupled planar antenna with wide bandwidth[J]. IEEE Transactions on Antennas and Propagation, 2003, 51(3): 441-448. doi: 10.1109/TAP.2003.809842.

薛飞, 王宏建, 董兴超. 新型单层双频双极化微带反射阵天线的设计[J]. 电子与信息学报, 2017, 39(3): 697-702. doi: 10.11999/JEIT160332.

XUE Fei, WANG Hongjian, and DONG Xingchao. Design of a novel single layer dual-band dual-polarization microstrip reflectarray antenna[J]. Journal of Electronics Information Technology, 2017, 39(3): 697-702. doi: 10.11999/JEIT160332.

高喜, 思敏, 刘扬清, 等. 宽带双极化四脊喇叭馈源研究[J]. 电波科学学报, 2013, 28(2): 337-340.

GAO Xi, LI Simin, LIU Yangqing, et al. Broadband and dual-polarized horn feed source[J]. Chinese Journal of Radio Science, 2013, 28(2): 337-340.

ZHAI Guohua, CHENG Yong, YIN Qiuyan, et al. Gain enhancement of printed log-periodic dipole array antenna using director cell[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(8): 5915-5919. doi: 10.1109/TAP.2014. 2355851.

ZHAI Guohua, HONG Wei, WU Ke, et al. Wideband substrate integrated printed log-periodic dipole array antenna[J]. IET Microwaves, Antennas Propagation, 2010, 4(7): 899-905. doi: 10.1049/iet-map.2009.0305..

伍捍东, 王晓娜, 任宇辉, 等. 基于缺陷地结构的宽带双极化天线设计[C]. 2013年全国天线年会, 广州, 2013: 96-199.

WU Handong, WANG Xiaona, REN Yuhui, et al. New dual- polarized micro-strip dipole antenna by loading DGS[C]. 2013 National Conference on Antenna of China, Guangzhou, 2013: 196-199.

REN Yuhui, DING Jun, GUO Chenjiang, et al. A wideband dual-polarized printed antenna based on CSRRs[J]. IEEE Antennas Wireless Propagation Letters, 2015, 14: 410-413. doi: 10.1109/LAWP.2014.2367126.

REN Yuhui, DING Jun, GUO Chenjiang, et al. A wideband gain-enhanced dual-polarized printed antenna based on log- periodic parasitic directors (LPPDs)[J]. Journal of Electromagnetic Waves and Applications, 2016, 30(8): 1021-1031. doi: 10.1080/09205071.2016.1168751.

YOO M and LIM S. SRR-and CSRR-loaded ultra-wideband (UWB) antenna with tri-band notch capability[J]. Journal of Electromagnetic Waves and Applications, 2013, 27(8): 2190-2197. doi: 10.1080/09205071.2013.837013.

张明旭, 龚书喜, 刘英. 利用接地板开槽减缩微带贴片天线的RCS [J]. 电子与信息学报, 2008, 30(2): 498-500.

ZHANG Mingxu, GONG Shuxi, and LIU Ying. Reducing the RCS of microstrip patch antenna by cutting slots on the ground plane[J]. Journal of Electronics Information Technology, 2008, 30(2): 498-500.

刘红喜, 高军, 曹祥玉, 等. 一种基于开口谐振环的高增益端射天线设计[J]. 物理学报, 2015, 64(23): 234101. doi: 10.7498/ aps.64.234101.

LIU Hongxi, GAO Jun, CAO Xiangyu, et al. A design of high-gain end-fire antenna based on split-ring resonator structures[J]. Acta Physica Sinica, 2015, 64(23): 234101. doi: 10.7498/aps.64.234101.

MARQUES R, MEDINA F, and RAFII-EL-LDRISSI R. Role of bianisotropy in negative permeability and left-handed metamaterials[J]. Physical Review B, 2002, 65: 144440. doi: 10.1103/PhysRevB.65.144440.
