基于分数阶傅里叶变换的窄带雷达飞机目标回波特征提取方法

杜兰; 史蕙若; 李林森; 孙永光; 胡靖

doi:10.11999/JEIT161035

基于分数阶傅里叶变换的窄带雷达飞机目标回波特征提取方法

doi: 10.11999/JEIT161035

基金项目:

国家自然科学基金(61271024, 61322103)，高等学校博士学科点专项科研基金博士生导师类基金(20130203110013)，陕西省自然科学基础研究计划(2015JZ016)

计量
- 文章访问数: 1551
- HTML全文浏览量: 121
- PDF下载量: 297
- 被引次数: 0
出版历程
- 收稿日期: 2016-10-08
- 修回日期: 2016-12-01
- 刊出日期: 2016-12-19

Feature Extraction Method of Narrow-band Radar Airplane Signatures Based on Fractional Fourier Transform

Funds:

The National Natural Science Foundation of China (61271024, 61322103), The Foundation for Doctoral Supervisor of China (20130203110013), The Natural Science Foundation of Shaanxi Province (2015JZ016)

摘要

摘要: 该文研究了常规窄带雷达体制下，利用分数阶傅里叶变换扩展特征域，从而解决直升机、螺旋桨飞机和喷气式飞机3类飞机目标回波分类中的特征提取问题。在现代战场中，直升机、螺旋桨飞机和喷气式飞机具有不同的机动性能，并各自承担着重要的任务。因此，实现这3类飞机的分类具有重大的意义。该文针对3类飞机目标分类的传统特征数目少，包含信息量有限，导致分类性能不够好的问题，基于现有的特征提取方法引入分数阶傅里叶变换(Fractional Fourier Transform, FrFT)，在经过FrFT后的分数域提取3类飞机目标回波的分数阶特征，弥补传统特征的不足。并利用线性相关向量机(Relevance Vector Machine, RVM)的特征选择功能对提取的分数阶特征进行特征选择并分类。基于仿真和实测数据的实验结果证明该文提出的分数阶特征的分类性能较传统时域、多普勒域特征有较大提升。
- 窄带雷达 /
- 分数阶傅里叶变换 /
- 特征提取 /
- 特征选择 /
- 目标分类 /
- 喷气引擎调制
Abstract: This paper studies on the feature extraction methods for the classification of helicopter, propeller-driven aircraft, and turbojet using a conventional narrow-band radar system. In the modern battlefield, the helicopter, propeller aircraft and jet aircraft with different motor performances each bear an important task. But the classification performance of the traditional features for the three types of aircraft target classification is not good enough, so the Fractional Fourier Transform (FrFT) is introduced. Based on the existing feature extraction method, the fractional order features of three kinds of aircraft targets are extracted from the fractional domain after FrFT to extend feature domain. Then, the effective features are selected from all extracted features and the classification of the three categories via linear Relevance Vector Machine (RVM) is realized. The experiments demonstrate that the proposed fractional features can improve the classification performance in comparison with some existing features from the time-domain and Doppler-frequency domain.
- Narrow band radar /
- Fractional Fourier Transform (FrFT) /
- Feature extraction /
- Feature selection /
- Target classification /
- Jet Engine Modulation (JEM)

HTML全文

参考文献(24)

CHEN V C. Radar signatures of rotor blades[J]. SPIE, 2001, 4391(1): 63-70. doi: 10.1117/12.421231.

YONG Y W, HOON P J, WOO B J, et al. Automatic feature extraction from jet engine modulation signals based on an image processing method[J]. IET Radar, Sonar Navigation, 2015, 9(7): 783-789. doi: 10.1049/iet-rsn.2014. 0281.

杜兰, 李林森, 李玮璐, 等. 基于时域回波相关性特征的飞机目标分类方[J]. 雷达学报, 2015, 4(6): 621-629. doi: 10.12000 /JR15117.

DU Lan, LI Linsen, LI Weilu, et al. Aircraft target classification based on correlation features from time domain echoes[J]. Journal of Radars, 2015, 4(6): 621-629. doi: 10. 12000/JR15117.

陈娟. 基于多特征融合的雷达目标识别[D]. [硕士论文], 西安电子科技大学, 2010.

CHEN Juan. Radar target recognition based on multi- features fusion[D]. [Master dissertation], Xidian University, 2010.

陶然, 齐林, 王越. 分数阶Fourier变换的原理与应用[M]. 北京: 清华大学出版社, 2004: 3-4, 31-45.

TAO Ran, QI Lin, and WANG Yue. Principle and Application of Fractional Fourier Transform[M]. Beijing: Tsinghua University Press, 2004: 3-4, 31-45.

OZAKTAS H M and BARSHAN B. Convolution, filtering, and multiplexing in fractional Fourier domains and their relation to LFM and wavelet transforms[J]. Journal of the Optical Society of America A-Optics Image Science and Vision, 1993, 11(2): 547-559. doi: 10.1364/JOSAA.11. 000547.

PENG Hsiaowei, CHANG Hsuanting, and LIN Chingchou. 2-D linear frequency modulation signal separation using fractional Fourier transform[C]. International Symposium on Computer Consumer and Control, Xian, 2016: 755-758. doi: 10.1109/IS3C.2016.193.

LI Y B, ZHANG F, KANG X J, at al. Image encryption based on the iterative fractional Fourier transform and a novel pixel scrambling technique[C]. IET International Radar Conference, Hangzhou, 2015: 1-6. doi: 10.1049/cp.2015.1036.

冉启文. 小波变换与分数阶傅里叶变换理论及应用[M]. 哈尔滨: 哈尔滨工业大学出版社, 2001: 1-7.

RAN Qiwen. Theory and Application of Wavelet Transform

and Fractional Fourier Transform[M]. Harbin: Harbin Institute of Technology Press, 2001: 1-7.

GUAN J, CHEN X L, HUANG Y, at al. Adaptive fractional Fourier transform based detection algorithm for moving target in heavy sea clutter[J]. IET Radar, Sonar Navigation, 2012, 6(5): 389-401. doi: 10.1049/iet-rsn.2011. 0030.

王亚星. 基于分数阶傅里叶变换的人脸识别[D]. [硕士论文], 郑州大学, 2015

WANG Yaxing. Human facial expression recognition based on fractional Fourier transform[D]. [Master dissertation], Zhengzhou University, 2015.

OZAKTAS H M, ARIKAN O, KUTAY M A, et al. Digital computation of the fractional Fourier transform[J]. IEEE Transactons on Signal Processing, 1996, 44(9): 2141-2150.

李志鹏, 马田香, 杜兰, 等. 在雷达HRRP识别中多特征融合多类分类器设计[J]. 西安电子科技大学学报, 2013, 40(1): 111-117. doi: 10.3969/j.issn.1001-2400.2013.01.020.

LI Zhipeng, MA Tianxiang, DU Lan, et al. Multi-class classifier design for feature fusion in radar HRRP recognition [J]. Journal of Xidian University , 2013, 40(1): 111-117. doi: 10.3969/j.issn.1001-2400.2013.01.020.

王宝帅, 杜兰, 刘宏伟. 基于经验模态分解的空中飞机目标分类[J]. 电子与信息学报, 2012, 34(9): 2116-2121. doi: 10. 3724/SP.J.1146.2012.00147.

WANG Baoshuai, DU Lan, and LIU Hongwei. Aircraft classification based on empirical mode decomposition[J]. Journal of Electronics Information Technology, 2012, 34(9): 2116-2121. doi: 10.3724/SP.J.1146.2012.00147.

MARTIN J and MULGREW B. Analysis of the theoretical radar return signal from aircraft propeller blades[C]. IEEE International Conference Radar, New York, USA, 1990: 569-572.

BELL M R and GRUBBS R A. JEM modeling and measurement for radar target identification[J]. IEEE Transactions on Aerospace and Electronic Systems, 1993, 29(1): 73-87. doi: 10.1109/7.249114.
