一种新型毫米波磁电偶极子天线阵列设计

陆贵文; 李明鉴

doi:10.11999/JEIT150038

一种新型毫米波磁电偶极子天线阵列设计

doi: 10.11999/JEIT150038

陆贵文¹,
李明鉴¹

基金项目:

中国香港RGC项目(9041677(CityU 119511))

计量
- 文章访问数: 1820
- HTML全文浏览量: 261
- PDF下载量: 1280
- 被引次数: 0
出版历程
- 收稿日期: 2015-01-08
- 修回日期: 2015-06-03
- 刊出日期: 2015-10-19

Novel Millimeter-wave Magneto-electric Dipole Antenna Array

Luk Kwai-man¹,
Li Ming-jian¹

Funds:

The RGC Item of Hong Kong (9041677(CityU 119511))

摘要

摘要: 该文将磁电偶极子天线作为辐射阵子，并应用一种共面波导馈电网络，研究并设计了一种新型44毫米波天线阵列。这种设计不仅具有很宽的阻抗带宽和增益带宽，而且价格低廉易于生产。仿真和测试结果表明，此天线阵列的相对阻抗带宽为54.5%, 3 dB增益带宽为37.1%，在工作频带内(40.2~70.0 GHz)，最大增益为18.1 dBi。而基于其他技术设计的44毫米波天线阵列(如微带天线、偶极子天线)工作频带宽度一般在20%左右，增益一般在16~17 dBi。所以该文提出的天线阵列设计具有明显的优势。另外，仿真设计结果和实测的电参数数据有较好的一致性。
- 毫米波天线阵列 /
- 磁电偶极子天线 /
- 宽带天线
Abstract: This paper presents a new 44 millimeter-wave antenna array, which adopts the magneto-electric dipole as the radiating element and a type of coplanar waveguide feed network to excite the array. This design not only provides very wide impedance and gain bandwidths, but also has features of low cost and ease in fabrication. The simulated and measured results reveal that this array exhibits a wide impedance bandwidth of 54.5% and a wide 3 dB gain bandwidth of 37.1%. Over the operating frequency band (40.2~70.0 GHz), the maximum gain is 18.1 dBi. However, other 44 millimeter-wave antenna arrays, designed based on microstrip patch antenna or electric dipole antenna, have the operating bandwidth of about 20% and the gain of 16~17 dBi. Hence, the proposed antenna has an obvious advantage. In addition, the simulated and measured results have a good agreement.
- Millimeter-wave antenna array /
- Magneto-electric dipole antenna /
- Wideband antenna

HTML全文

参考文献(17)

Li Ming-jian and Luk Kwai-man. Low cost wideband microstrip antenna array for 60-GHz applications[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(6): 3012-3018.

Sun Hu-cheng, Guo Yong-xin, and Wang Zi-liang. 60 GHz circularly polarized U-slot patch antenna array on LTCC[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(1): 430-435.

Chin Kuo-sheng, Jiang Wen, Che Wen-quan, et al.. Wideband LTCC 60 GHz antenna array with a dual-resonant slot and patch structure[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(1): 174-182.

Li Yu-jian and Luk Kwai-man. Low-cost high-gain and broadband substrate-integrated-waveguide-fed patch antenna array for 60-GHz band[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(11): 5531-5538.

Yeap Siew Bee, Chen Zhi-ning, and Qing Xian-ming. Gain-enhanced 60-GHz LTCC antenna array with open air cavities[J]. IEEE Transactions on Antennas and Propagation, 2011, 59(9): 3470-3473.

李雨键, 陆贵文. 60 GHz高介电常数介质贴片天线阵[C]. 全国天线年会, 广州, 2013: 734-737.

Li Yu-jian and Luk Kwai-man. 60 GHz dense dielectric patch antenna array[C]. National Conference on Antennas, Guang zhou, 2013: 734-737.

Li Yu-jian and Luk Kwai-man. A 60 GHz dense dielectric patch antenna array[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(2): 960-963.

Chen Xiao-ping, Wu Ke, Han Liang, et al.. Low-cost high gain planar antenna array for 60 GHz band applications[J]. IEEE Transactions on Antennas and Propagation, 2010, 58(6): 2126-2129.

Xu Jun-feng, Chen Zhi-ning, Qing Xian-ming, et al.. Bandwidth enhancement for a 60 GHz substrate integrated waveguide fed cavity array antenna on LTCC[J]. IEEE Transactions on Antennas and Propagation, 2011, 59(3): 826-832.

Gong Ke, Chen Zhi-ning, Qing Xian-ming, et al.. Substrate integrated waveguide cavity-backed wide slot antenna for 60 GHz bands[J]. IEEE Transactions on Antennas and Propagation, 2012, 60(12): 6023-6026.

Kramer O, Djerafi T, and Wu Ke. Very small footprint 60 GHz stacked yagi antenna array[J]. IEEE Transactions on Antennas and Propagation, 2011, 59(9): 3204-3210.

Chu Hui, Guo Yong-xin, and Wang Zi-liang. 60 GHz LTCC wideband vertical off-center dipole antenna and arrays[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(1): 153-161.

Zhang Bing and Zhang Yue-ping. Grid array antennas with subarrays and multiple feeds for 60 GHz radios[J]. IEEE Transactions on Antennas and Propagation, 2012, 60(5): 2270-2275.

Liu Chang-rong, Guo Yong-xin, Bao Xiao-yue, et al.. 60-GHz LTCC integrated circularly polarized helical antenna array [J]. IEEE Transactions on Antennas and Propagation, 2012, 60(3): 1329-1335.

Luk Kwai-man and Wong Hang. A new wideband unidirectional antenna element[J]. International Journal of Microwave and Optical Technology, 2006, 1(1): 35-44.

Luk Kwai-man and Li Ming-jian. Magneto-electric dipole antennas for millimeter-wave applications[C]. 2013 Asia- Pacific Microwave Conference Proceedings, Seoul, Korea, 2013: 304-306.
