动态分形粗糙海面散射的遮蔽效应和多普勒谱研究

郭立新; 任玉超; 吴振森

动态分形粗糙海面散射的遮蔽效应和多普勒谱研究

计量
- 文章访问数: 2743
- HTML全文浏览量: 95
- PDF下载量: 885
- 被引次数: 0
出版历程
- 收稿日期: 2004-04-21
- 修回日期: 2004-08-23
- 刊出日期: 2005-10-19

Study on the Shadowing Effect and Doppler Spectra for the Scattering from the Time-Varying Fractal Rough Sea Surface

摘要

摘要: 利用粗糙面电磁散射中的基尔霍夫近似，结合粗糙面遮蔽函数和分形粗糙海面特征函数的计算，导出了考虑遮蔽效应情况下导体分形粗糙海面散射截面的近似公式。研究了海面不同均方根斜率对遮蔽效应的影响。比较了毫米波入射时高斯粗糙面和分形粗糙海面的散射截面分布情况。分析了不同分维下分形海面双站散射截面的角分布情况。详细讨论了不同入射角和不同分维及遮蔽效应对分形海面散射回波多普勒谱的影响。
- 分形粗糙海面;电磁散射;遮蔽效应; 多普勒谱
Abstract: According to the Kirchhoff approximation for the rough surface scattering and by calculating the shadowing function and characteristic function of the fractal rough sea surface, the formula of the scattering cross section for the conducting fractal sea surface is derived with consideration of the shadowing effect. The influence of the shadowing effect for different RMS slope of the surface is investigated. The distribution of the scattering cross-section for the Gaussian rough surface and fractal rough sea surface is compared with millimeter wave incidence. The angular distribution of the bistatic scattering cross-section from fractal sea surface for different fractal dimension and different spatial frequency is analyzed. The influence of different incident angle, different fractal dimension and shadowing effect on the Doppler spectra of the echo from the fractal sea surface is discussed in detail.

HTML全文

参考文献(1)

Ulaby F T, Moore R K, Fung A K. Microwave Remote Sensing. Vol.II, Reading, MA: Addision -Wesbey Publishing, 1982, chap.12.[2]Lin N. Wave scattering from fractal surface[J].J. of Modern Opt.1995, 42(1):225-241[3]Berizzi F, Dalle-Mese E. Fractal analysis of the signal scattered from the sea surface[J].IEEE Trans. on Antennas Propag.1999, 47(2):324-338[4]Ranceschetti G, Iodice A. Scattering from natural rough surface modeled by fractional Brownian motion two-dimensional[5]processes. IEEE Trans[J].on Antennas Propag.1999, 47(9):1405-1415[6]Guo Lixin, Wu Zhensen. Fractal characteristics investigation on light scattering from two dimensional rough surface[J].Int. J. Infrared and Mill. Wave.2000, 21(12):2099-2106[7]Donnell K A, Mendez E R. Experimental study of scattering from characterized random surfaces[J].J. Opt. Soc. Am.1987, 4(7):1194-1205[8]Bourlier C, Berginc G, Saillard J. One and two-dimension shadowing functions for height and slope stationary uncorrelated surface in the monostatic and bistatic configuration[J].IEEE Trans. on Antennas Propagat.2002, 50(2):312-324[9]Bourlier C, Saillard J, Berginc G. The shadowing function. Prog. Electromagn. Res., 2000, 27: 225-287.[10]郭立新, 吴振森. 考虑海谱分布的动态分形海面的电磁散射. 电子学报, 2001, 29(9): 1287-1289.[11]Thorsos E I. Acoustic scattering from a Pierson -Moskowitz sea surface[J].J. Acoust. Soc. Am.1990, 88(1):335-349[12]Bourlier C, Berginc G, Saillard J. Bistatic scattering coefficient from one- and two- dimensional randomly rough surface using the stationary phase and scalar random approximation with shadowing effect: comparisons with experiments and application to the sea surface[J].Waves in Random Media.2001, 11(1):119-147[13]Zavorotny V U, Voronovic A G. Two-scale model and ocean radar Doppler spectra at moderate and low-grazing angles. IEEE Trans. on Antennas Propagat., 1998, 36(1): 84-92.
