开关电容网络Z域分析的回路电荷法
A LOOP CHARGE METHOD FOR THE Z-DOMAIN ANALYSIS OF SWITCHED-CAPACITOR NETWORKS
-
摘要: 本文导出了一般开关电容支路的Z域电荷耦合模型,提出一种适用于多相开关电容网络Z域分析的回路电荷法。Abstract: A derivation of the Z-domain charge coupled model is given for a general switched-capacitor branch. A new loop charge method for the Z-domain analysis of multiphase switched-capacitor networks is presented.
-
Laker K R. Bell Syst. Tech. J. 1979, 58(3):727-767.[2]Vandewalle J. DeMan H, Rabaey J. IEEE Trans. on CAS, 1981, CAS-28(3):186-195.[3]Hokenek E, Moschylz G S. Proc. IEE, 1980, 127(1):226-241.[4]Bruton L T, Batley G R, Bbattaeharjee G. Loop equation formulation for switched-capacitor neworks containing nullors. Proc. IEEE Int. Symp. on Circuit and Systems, Rome. Italy:[5]May 1981. 29-32. -
