单轴介质加载鳍线的谱域导抗法
A SPECTRAL-DOMAIN IMMITTANCE APPROACH FOR FIN LINES WITH UN1AX1ALLY AN1SOTROPIC SUBSTRATES
-
摘要: 本文通过分析和推导,将谱域导抗法扩展到单轴介质加载鳍线的特性分析。单轴介质的光轴方向既可平行又可垂直于介质分界面。通过对称双侧鳍线的有效介电常数的数值计算,验证了本文方法的正确性。Abstract: A characteristic analysis of the finlines with uniaxially anisotropic substrates using the spectral-domain immittance approach is presented. The optical axis of uniaxial substrate is either perpendicular or parallel to the substrate plane. This approach is tested to be correct, through the numerical calculation of the effective dielectric constant of a bilateral symmetry finlines.
-
T. Itoh, IBEF. Trons, on MTT, MTT-28(1980)7, 733-736.[2]T. Itoh, W. Menzel. IEEE Trans. on AP, AP-29(1981)1, 63-68.[3]A.-A, T. K. Shalaby, A Kumar, IEEE Trans. on MTT, MTT-35(1987)4, 448-450.[4]R. M. Nelson, D. A. Rogers, A. G. Dassuncao, IEEE Trans. on AP, AP-38(1990)7, 973-981.[5]H.C. Chen著,梁昌洪等译,电磁波理论无坐标方法,电子工业出版社,北京,1988年.[6]H-Y. Yang, N. G. Alexopoulos, IEEE Trans. on MTT, MTT-35(1987)1, 24 -29. -
