一种新型基站天线的非均匀网格FDTD分析
Analysis of a novel base stationi antenna with non-uniform FDTD
-
摘要: 板状振子型基站天线是一种现代移动通信中广泛使用的基站天线。为了比较准确地对其天线单元和槽形板进行建模,同时考虑到计算资源限制,该文应用一种非均匀网格FDTD方法对其辐射方向图特性进行了分析。数值结果表明该文方法处理天线辐射问题的有效性。
-
关键词:
- 基站天线; 非均匀网格FDTD; 方向图
Abstract: The dipole antenna array with trough reflector is widely applied to base stations for mobile communications. In order to simulate the antenna units and the trough reflector accurately and take the limitation of computation resources into account, this paper employs a kind of non-uniform FDTD algorithm in analyzing the radiation pattern. The numerical results show the effectiveness of this algorithm for antenna problems. -
K.S. Yee , Numerical solution of initial boundary value problems involving Maxwells equations in isotropic media, IEEE Trans. on AP, 1966, 14(5), 302 307.[2]Jiang Huiling, Analysis of computation error in antennas simulation by using non-uniform mesh FDTD, IEICE Trans., E00-A, No.1 January 1998, 1-9.[3]R. Luebbers, L. Chen, T. Uno, S. Adachi, FDTD calculation of radiation patterns, impedance,and gain for monopole antenna on a conducting box, IEEE Trans. on AP, 1992, 40(11), 1577-1583.[4]汪茂光,几何绕射理论,西安,西安电子科技大学出版社,1994,70-71.[5]Jian Peng, A. Balanis, NEC and ESP codes: Guidelines, limitations, and EMC applications,IEEE Trans. on EMC, 1993, 35(2), 124-133. -
