适于一维相控阵宽角扫描的非对称单脊波导裂缝线源
ASYMMETRIC RIDGE WAVEGUIDE SLOT LINEAR ARRAY FOR ONE DEMENSION IDE SCAN-ANGLE PHASED ARRAY
-
摘要: 非对称单脊波导裂缝线源是一种新型相控阵天线辐射单元。由该种单元垂直放置构成的平面相控阵天线在水平面可实现宽角(60)扫描,在波束扫描时,还可以避免寄生副瓣的出现。同时,该种单元本身在垂直面易于实现较低的副瓣电平。本文从理论和实验上对非对称单脊波导裂缝阵天线进行了研究,解决了该种线源设计过程中的基本理论和关键技术。十六单元样品线源远场实验结果与理论值的一致性说明了本文的理论分析和实现途径是正确有效的。Abstract: An asymmetric ridge waveguide slot array is a novel linear array radiating element for phased array antenna.The phased array can scan to wide angle (60)in azimuth,and can eliminate the secondary beams when the beam is scanned, which is consisted of many vertical asymmetric ridge waveguide slot linear array elements. And at the same time, the linear array can be easy to get low side-lobe. The theoretical and experimental studies for the linear array are presented in this paper. The basic theory and key technique for the linear array are performed on which systematic design procedure can be based.A constructed sixteen-slot array is tested under the far field, the results in agreement with the theory validate the theoretical analysis and the design proceduce for collinear slot array of asymmetric ridge waveguide.
-
Green J,Shnitkin H.Asymmetric ridge waveguide radiating element for a scanned planar array.IEEE Trans.on AP,1990,AP-38(8):161-165.[2]Elliott R S.The design of small slot arrays. IEEE Trans.on AP,1978,AP-26(2):214-219.[3]鲁加国,樊德森.非对称单脊波导的积分方程法分析.微波学报,1998,14(2)：108-115.[4]鲁加国,吴双桂,张祖稷.非对称单脊波导孤立缝导纳.无线电通信技术,1998,24(4)：56-59.[5]鲁加国,吴双桂,陈嗣乔.非对称单脊波导裂缝阵天线分析.电波科学学报,1998,13(4)：388-392. -
