210270GHz短毫米波3倍频器
A MILLIMETER WAVE FREQUENCY TRIPLER COVERING 210-270GHz
-
摘要: 本文描述了频率复盖210270GHz的3倍频器,最高的倍频效率为5.8%,最大的输出功率发生在输入功率为3050mW的范围内。3倍频器是由基波输入波导WR-12、输出波导WR-4和两波导之间的同轴低通滤波器组成。
-
关键词:
- 毫米波; 3倍频器; 低通滤波器
Abstract: A frequency tripler covering 210-270 GHz frequency band with a peak efficiency of 5.8% is lescribed. The maximum output power occurs at input power of 30-50 mW. The frequency tripler consists of an input waveguide WR-12, an output waveguide WR-4 and a coxial low pass filter between them. -
