S波段20W脉冲耿氏振荡器
AN S-BAND 20W PULSE GUNN OSCILLATOR
-
摘要: 本文描述了脉冲耿氏二极管、微波电路、脉冲调制器的结构和设计原则;给出了脉冲耿氏振荡器研制结果:在3--4GHz范围内,最大脉冲功率为20W,最大效率为5%,工作比1%。
-
关键词:
- 脉冲耿氏管; 微波电路; 脉冲调制器
Abstract: The design principles and structure, characters of a kind of pulse Cunndiode, microwave circuit and pulse modulator are described. The performances of the developed pulse Gunn oscillator are as follows: in the frequency range of 3-4 GHz, the maximum pulse power is 20W, the highest efficiency is 5% and the maximum pulse duration ratio is less than 1%. -
谢家德,微波,1987年,第3期,第35-43页.[2]谢家德,电子学报,1988年,第4期,第118-119页. -
