讯号对网络的匹配及其应用
THE MATCHING OF SIGNAL TO A NETWORK AND ITS APPLICATIONS
-
摘要: 本文提出了讯号对网络匹配的概念,在分析某些微波网络时应用这一概念,可使问题简单明了。文中给出了一个应用实例。
-
关键词:
Abstract: A new concept about the matching of signal to a network is proposed. For an n-port microwave network, if all incident waves are proportional to the conjugates of oorresponding scattermg parameters of network S* ki(i = 1 n), then the ratio of the power of scattering wave at the k-th port to the sum of power of all incident waves reaehes the maximum. Using this concept, we find some problems may be simplified when microwave networks are studied. To illustrale application of the concept, a description of an ultrabroad-band line transformer and an antenna array is given in this paper. -
《数学手册》编写组,数学手册,人民教育出版社,1979年,第21页.[2]林守远,雷达技术,1979年,第4期,第19页.[4]U. Barabas, IEEE Trans. on MTT, MTT-27 (1979), 58.
