吸波涂层目标散射特性的复射线分析
COMPLEX RAY ANALYSIS OF SCATTERING FROM RAM COATED TARGETS
-
摘要: 将复射线理论推广到媒质有耗的情形,可以建立起损耗媒质中的复射线方法并用来分析吸波涂层目标的散射特性。该方法具有计算简便、物理概念明确、适用范围较广等特点。本文以涂层金属平板为例所进行的目标雷达截面分析结果表明,理论计算与实验结果能够很好地吻合。
-
关键词:
- 吸波材料; 雷达截面; 复射线法
Abstract: With the extension of complex ray theory (CRT) from lossless media intolossy ones, the complex ray analysis in lossy media can be constracted, and effectively used in the problems of scattering analysis of objects coated with radar absorbing materials (RAM). This method has advantages, such as simple calculation procedure, clear physical meaning, wide applicanon area etc. As an example, the radar cross-section (RCS) of conducting flat plates coated with RAM is analyzed. The results show that the theoretical predictions agree very well with the experimental results. -
E. F. Knott等著,阮颖铮等译,雷达散射截面预估、测量和减缩,电子工业出版社,北京,1988年11月.[2]徐晓文,涂层目标散射特性及其模型侧量的理论研究,电子科技大学博士学位论文,成都,1989年.[3]H. Ling, R. C. Chou, S.W. Lee, IEEE Trans. on AP, AP-37 (1989) 2,194-205.[4]R. Mittra (ed.), Computer Techniques for Electromagnetics, Pergamon Press, New York, (1973).[5]阮成礼,王秉中,部分涂覆机冀结构RCS研究,军用目标特性和传输特性论文与简要汇编,1989年,青岛,第60-60页.[6]阮颖铮,电子学报,17(1989)3, 89-94.[7]M. Born, E. Wolf, Principle of Optics, 6th ed. Pergamon Press, New York, (1980).[8]阮颖铮编著,电磁射线理论基础,成都电讯工程学院出版社,成都,1989年4月.[9]阮颖铮,杜惠平,应用科学学报,10(1992)2,13-19.[10]阮颖铮,L. B. Felsen,应用科学学报,7 (1989) 2, 174-177.[11]阮颖铮,电子科学学刊,11 (1989) 4, 368-377.[12]冯文澜,阮颖铮,电子科学学刊,12(1990)6, 664-667.[13]R. A. Ross, IEEE. Trans. on AP, AP-14 (1966) 3, 329-335.[14]贾宝福,强扰动理论及其在隐身用吸波材料研究中的应用,电子科技大学博士学位论文,成都,1989年.[15]阮颖铮,杜惠平,电子科技大学学报,20 (1991)4, 368-374. -
