摘要:
本文提出了设计宽带速调管滤波器型输出回路的新的设计标准和相应的设计方法,由此可以求得符合速调管设计要求,并具有最大阻抗频带特性的输出段。本文还从等效电路出发,直接计算间隙作用阻抗,并求得输出回路各参数对阻抗-频带特性的影响,根据计算曲线,调整输出回路参数,可在实际研制工作中求得最佳结果。
Abstract:
In this paper, we propose a new eriterion and a method for designing filter type output circuit of broadband klystrons. From this, we ean obtain an output section which satisfies the requirement of klystron designs, and have good impedance-band-width characteristies. From equivalent circuit, we can directly calculate the gap in-teraction impedance, and obtain the effect of parameters of the output circuit on which the impedance-bandwidth characteristies depends. According to caleulated curves, we can get optimum results through adjusting the parameters of output circuit in the actual manufacture.
