容差参数的阵列天线方向图综合法
TOLERANCE SYNTHESIS TECHNIQUE FOR ARRAYS RADIATION PATTERN
-
摘要: 本文研究了设计参数具有容差的阵列天线方向图综合法;给出了阵列天线容差优化的数学模型;提出了求解容差优化问题的数学方法;建立了直线阵列天线容差区内误差任意分布的物理模型;并对激励幅度具有容差的侧射天线阵进行了计算。本文的方法可以最大限度地避免设计参数容差对天线性能的影响。
-
关键词:
- 阵列天线; 容差优化; 数学模型
Abstract: Tolerance synthesis techniques of array radiation pattern are investigated. The mathematical models for array radiation pattern optimization are given, and the methods for solving the problem of tolerance optimization are initiated. The physical model for arbitrary tolerance distribution of array elements is presented. Numerical examples are given for the broadside array in which the excitation amplitude coefficients have tolerances. The methods given in this paper immunize optimally the resulting arrays against the deviations of the design parameters from their nominal values. -
D. M. Pozar, IEEE Trans. on AP, AP-38(1990)8, 1176-1185.[2]H. Schiaer-Jacobsen, IEEE Trans on AP, AP-28(1980)2, 247-250.[3]H. Schiaer-Jacobsen, K. Madsen, IEEE Trans. on CAS, CAS-26(1979)9, 775-783.[4]焦永昌, 约束优化研究及在天线优化设计中的应用,西安电子科技大学博士学位论文,1990年，第32- 34页.[5]Qi Yihong, Jiao Yongchang, Worst Case Tolerance Optimization of Arrays Radiation Pattern. APMC, (1992). -
