开关电流网络的信号流图分析法
SIGNAL-FLOW GRAPH ANALYSING METHOD FOR SWITCHED CURRENT NETWORKS
-
摘要: 开关电流作为一种新的电流模式技术已经成为电流模式信号处理的前沿课题。本文引入偶镜和奇镜的概念,提出了开关电流网络的信号流图分析法,并把它用于对开关电流滤波器的分析研究。计算机仿真结果验证了本文方法的正确性和可行性。
-
关键词:
- 开关电流; 奇镜; 偶镜
Abstract: As a new current-mode technique, switched current has been in a forward position of current-mode analog signal processing. This paper submitted a signal-flaw graph analysing method for switched current networks by introducing concepts of odd mirror and even mirror, and applied them to analyse the switched current filter. The result of computer simulation verified the reliability and feasibility of the method. -
Hughes J B. Switched Current A New Technique for Analogue Sampled-Data Signal Processing. IEEE ISCAS, 1989, 1584-1587.[2]Hughes J B. Switched Current Filter, IEEE Proc., 1990, 137(2):156-162.[3]Fiez T S. CMOS Switclied-Current Biquadratic Filters. dEEE ISCAS, 1990, 2300-2303.[4]吴杰,洪毅.电子科学学刊,1992,14(6): 633-637.[5]杨嘉湜.开关电流滤波器分析研究:[硕士论文].湖南大学电气工程系,1994.[6]吴杰,洪毅.科学通报,1993,38(17): 1575-1577. -
