一般线性网络的混合分析法
THE MIXED ANALYSIS METHOD OF GENERAL LINEAR NETWORKS
-
摘要: 本文应用网络图论提出了圈-离集混合基矩阵的概念、混合基中基尔霍夫定律的矩阵表示和一般线性网络的混合基方程,进而建立了一般线性网络的圈电流-离集电压混合分析法。这个方法把文献[4]关于无源和无互感网络的混合分析法推广到包括有源和有互感网络在内的一般的线性时不变集总参数网络的情况。
-
关键词:
Abstract: In this paper, by applying the network graph theory, the concept of cycle-seg mixed basis matrix, the matrix representation of Kirchhoff s law in the mixed basis and the mixed basis equations of general linear networks are presented. Then the cycle current-seg voltage mixed analysis method of general linear networks is established. By this way, the mixed analysis method for passive networks without mutual inductances in referenee [4] is extended to one for active networks with mutual inductances. -
W. K. Chen, Applied Graph Theory, North-Holland Publishing Company, Amsterdam, London,1971, p. 36-76.[4]王春华,图论与网络拓扑分析,计算机辅助设计,科学技术文献出版社重庆分社,1979年,第1-15页.[5]张惠廉、庄镇泉,电子线路的计算机辅助设计,上册,人民教育出版社,1979年,第86-121页.[6]邱关源,网络图论简介,人民教育出版社,1978.[7]Claude Berge, Graphs and Hypergraphs, North-Fholland Publishing Company, Amsterdam, London,1973, p. 3-17. -
