IPO结合FMM，RPFMM，FaFFA方法快速计算电大腔体的RCS

罗威; 高正平

IPO结合FMM，RPFMM，FaFFA方法快速计算电大腔体的RCS

罗威,
高正平

计量
- 文章访问数: 2122
- HTML全文浏览量: 82
- PDF下载量: 998
- 被引次数: 0
出版历程
- 收稿日期: 2005-09-30
- 修回日期: 2006-03-20
- 刊出日期: 2006-12-19

The Fast Calculation of RCS of Electrically Large Open-Ended Cavities Combine IPO, FMM, RPFMM, FaFFA

摘要

摘要: 迭代物理光学法结合快速多极子(IPO+FMM)方法，可以快速计算电大腔体的电磁散射特性。传统的快速多极子(FMM)方法需要计算两组的转移因子以及转移过程的全部角谱分量，计算开销是非常大的。随着组间距离的增大，转移过程可以用射线多极子(RPFMM)简化计算，为了充分利用射线多极子方法中参与计算的有效角谱分量随着组间距离增大而变少的特性，采用一种随着组间距离增大自适应调整参与计算的角谱分量的锥形区域的射线多极子方法(RPFMM)，当两组距离足够大而位于远场时，用远场近似方法(FaFFA)进一步简化计算。结果表明该方法能在保持计算精度的同时并能较IPO+FMM方法进一步减少计算资源占用、提高计算速度。
- 迭代物理光学法; 腔体; 快速多极子方法; 射线多极子方法; 快速远场近似
Abstract: IPO+FMM method can rapidly solve the scattering of three-dimensional cavity. In the conventional Fast Multipole Method (FMM), at all directions of translation between two groups should be computed, it is expensive. The Ray-Propagation Fast Multipole Method (RPFMM) is applied to simplify the translation when two groups are well separated. In fact, the amount of translators to be calculated should be decrease with the increase of distance between two groups, to take full advantage of the characteristics; a self-adaptive ray-propagation fast multipole algorithm which can modulate the bound of cone zone of RPFMM is adopted. When the distance between two groups is enough large, Fast Far-Field Approximation (FaFFA) is used to further simplify the translation. The numerical results show this method is accurate enough and can improve efficient computing speed than IPO+FMM.

HTML全文

参考文献(1)

Basteiro Fernando, Rodriguez J L, Burkholder R J. An iterative physical optics approach for analyzing the electromagnetic scattering by large open-ended cavities[J].IEEE Trans. on Antennas and Propagation.1995, 43(4):356-361[2]Burkholder R J. A fast and Rapidly convergent iterative physical optics algorithm for computing the RCS of open-ended cavities. ACES Journal, 2001, 16(1): 53-59.[3]Liu J, Jin J M. A special higher order finite-element method for scattering by deep cavities[J].IEEE Trans. on Antennas Propag.2000, 48(5):694-703[4]Burkholder R J, Lundin T. Forward-Backward iterative physical optics algorithm for computing the RCS of open-ended cavities[J].IEEE Trans. on Antennas and Propagation.2005, 53(2):793-799[5]McCowen A. Eifficient 3-D moment-method analysis for reflector antennas using a far-field approximation technique. Proc. Inst. Elect. Eng., pt. H, Feb, 1999, vol.146: 7-12.[6]Cui Tie Jun, Chew Weng Cho, Chen Guang, Song Jiming M. Effiecient MLFMA, RPFMA, and FAFFA algorithms for EM scattering by very large structures[J].IEEE Trans. on Antennas and Propagation.2004, 52(3):759-770[7]胡劼, 胡俊, 聂在平等. 一种自适应的射线传播多极子方法电波科学学报, 2004, 19(6): 669-672.[8]Chew Weng Cho, Cui Tie Jun, Song Jiming M. A FAFFA_ MLFMA algorithm for electromagnetic scattering[J].IEEE Trans. on Antennas and Propagation.2002, 50(11):1641-1649[9]胡俊, 聂在平等. 三维大纵横比目标散射的快速精确求解. 电波科学学报, 2000, 15(2): 235-238.[10]王浩刚, 聂在平等. 对三维多层快速多极子方法中不变项计算的优化. 电子学报, 2000, 28(9): 105-108.
