基于电路三要素理论的2-5混值/十值计数器研究
Research of 2-5 Mixed-Valued/Ten-Valued Counter Based on Three Essential Circuit Elements
-
摘要: 通过对2-5混值编码原理、电路三要素理论和N +1值代数理论的分析,定量研究了2-5混值门电路、触发器和带进位/借位的加减法计数器,最后设计了2-5混值/十值译码电路,使计数器输出为十值信号。与以往十值电路的设计方法相比较,此设计方案具有编码效率高、供电电压低等特点。计算机模拟验证了上述理论和依此理论设计的电路的正确性。Abstract: By analyzing the principle of 2-5 mixed-valued coding, the theory of three essential circuit elements and the theory of N+1-valued algebra, the 2-5 mixed-valued gate circuits, flip-flops and up-down counters with carry/borrow bit are investigated quantitatively, the 2-5 mixed-valued/ten-valued encoder is designed in order to make the output of counter become ten-valued signal. Compared with the conventional design of ten-valued circuits, the design has the characteristics of high coding efficiency, low voltage supply, etc. Above theory and circuits based on this theory are verified by computer simulations.
-
吴训威著. 多值逻辑电路设计原理[M]. 杭州:杭州大学出版社,1994: 1-385.[2]杭国强, 吴训威. 基于开关信号理论的控阈技术与三值ECL施密特电路[J]. 电路与系统学报, 1998, 3(2): 15-20.[3]吴训威,陈偕雄 2-3混值编码与混值计数器[J]. 中国科学(A[4],1989,8:848-855.[5]吴训威, 汪鹏君, 夏银水. 三值施密特触发器的时序特征及其设计[J]. 电路与系统学报, 2000, 5(3): 72-74.[6]汪鹏君,盛法生,吴训威. 四值施密特电路设计[J]. 浙江大学学报, 2001, 28(4): 462-467.[7]方振贤, 刘莹. 三值电路和电路三要素理论[J]. 电子科学学刊, 1999, 21(4): 536-542.[8]方振贤,汪鹏君,刘莹. 二值、多值和绝热电路通用的电路理论[J]. 电子学报, 2003, 31(2): 303-305.[9]汪鹏君,方振贤,黄道,吴训威. 基于电路定量理论的五值门电路和触发器设计[J].固体电子学研究与进展, 2004, 24(2): 200-204.[10]方振贤,刘莹. 边沿取样电路和同步动态时序电路综合[J]. 电子学报, 1999, 27(5): 11-14.
