大规模电路的岛桥分析法
ISLAND-BRIDGE ANALYSIS FOR LARGE SCALE CIRCUIT
-
摘要: 对于一个n端子网络,如果能够得到每一端的端电流,那么这个子网络就可解了。本文将一个大网络分裂成P个子网络,并在n端子网络CCVS模型上提出了岛和桥的概念,进而得到岛方程,从而得到各子网络的端电流。这种方法在分析大规模电路时,对于提高运算速度和节省计算机内存具有一定实际意义。Abstract: A subnetwork is able to be solved, if its terminal currents have been determined. In this paper, the concepts of island and bridge are presented, the CCVS model of n-terminal subnetwork is constructed, the island equations are deduced and then the currents of each subnetwork terminal are obtained. Using this method, the computing time and the memory space can be saved.
-
Wu F F. IEEE Trans. on CAS, 1976, CAS-23(12):706-713.[2]刘佩仙,等.电子学报,1989,17(4): 107-109.[3]韩跃新.电子学报,1988,16(4),52-58.[4]黄东泉,等.电子科学学刊,1992,14(1): 15-20. -
