电离层人工调制的极低频辐射和在潜艇通信中的应用探讨

夏明耀; 陈志雨

电离层人工调制的极低频辐射和在潜艇通信中的应用探讨

计量
- 文章访问数: 2399
- HTML全文浏览量: 117
- PDF下载量: 457
- 被引次数: 0
出版历程
- 收稿日期: 1993-08-07
- 修回日期: 1994-01-08
- 刊出日期: 1995-03-19

INVESTIGATION OF ELF RADIATION GENERATED BY ARTIFICIALLY MODULATED IONOSPHERE AND ITS APPLICABILITY TO COMMUNICATION TO SUBMARINES

摘要

摘要: 本文分析被调制的高频波加热电离层所产生的极低频辐射过程和极低频在地球-电离层波导中的传播模式,以及应用于潜艇通信中的可能性。数值结果表明,如果高频有效发射功率为100MW量级,频率为5MHz,调制频率为100Hz,则准TEM模式在地球-电离层波导中传播的衰减率一般小于1dB/Mm,距加热地点1000km处海面(地面)上磁场强度的量级为10-8A/m。对于潜艇通信,在辐射源强度确定的情况下,对不同的潜艇深度和通信距离,存在一个最佳选择频率。
- 电离层人工调制; 极低频辐射; 准TEM模式
Abstract: Powerful HF waves modulated by ELF signals are employed to heat the lower ionosphere and generate ELF radiations that might be applicable to communication to submarines. Numerical results show that, if the frequency and effective radiation power(ERP) of the HF waves are 5MHz and 100MW respectively, with modulation frequency 100Hz, then the attenuation rates of the Quasi-TEM propagating in the earth-ionosphere waveguide are usually less than IdB/Mm, and the magnetic field strength 1000km away from the heating location is in the order of 10-8A/m. As for communication to submarines, for a specific ELF source and a given submarine location, there exists a most favorable frequency that maximizesthe receiving signals.

HTML全文

参考文献(1)

Rowe H E. IEEE Trans. on COM, 1974, COM-22(4): 371-385.[2]Fiel Jr. E C, Kies L R, Bannister[3]P R, et al. Radio Science, 1989, 24(2): 235-246.[4]Getmantsev G G, Zuikov N A, Rapoport V O, et al. JETP Lett., 1974, 20: 101-102.[5]Barr R,Stubbe R, Rietveld M T, et al. J. of Geophysical Research, 1986, 91(A4): 4451 -4459.[6]Barr R, Stubbe P. Radio Science. 1984. 1904): 1111-1122.[7]Stubbe P, Kopka H, Rietveld M T, et al. J. of Atmo[J].and Terr. Physics.1982, 44(12):1123-1135[8][7]Rietveld M T, Mauelshagen H P, Stubbe P, et al. J of Geophysical Research, 1987, 92(A8): 8707-8722.[9]Ferraro A J, Lee H S, Allshouse R, et al. J. of[10]Atmo. and Terr. Physics. 1984, 46(10):855-865.[11]Stubbe P, Varnum W S.[12]Planet Space Sci., 1972, 20: 1221-1226.[13]Chen Zhiyu. Xia Mingyao, The VLF/EEF Antenna Built[14]Heating the Lower Ionosphere at[15]Middle Latitudes, Proc. of the Third Internatinal Symposium on[16]Antennas and EM Theory. Nanjina, China: Sept. 1993, 132-135.[17]Chen, Zhiyu Xia, Mingyao The Primary VLF/ELF Current Produced by Heating the Lower Ionosphere above China. Pro c. of International Symposium on[18]Radio Propagation. Beijing, China: Aug. 1993, 497 -500.[19]Papadopoulos K, Chang C L, Vitello P,[20]et al. Ridio Science, 1990, 25(6): 1311-1320.[21]Galejs J. Radio Science, 1971. 6(1): 41-53.[22]Tripachi V K, C hang C L. Radio Science, 1982, 17(5): 1321-1326.[23]Wait J R. Electromagnetic Waves in Stratified Media. Oxford: Pergamon Yress, 1962.300-305.[24]Yeh K C, Liu C H. Theory of Ionospheric Waves. New York: Academic Press, 1972,121.
