测量互易多端口网络S参数的多短路活塞法的进一步改进
FURTHER IMPROVEMENT ON MEASURING S-PARAMETERS OF RECIPROCAL MULTIPORT NETWORK BY THE MULTI-MOVABLE SHORT METHOD
-
摘要: 本文提出互易多端口网络的广义等效二端口测量方程组,解决了S参数测量中被测网络的互等效参数的利用问题,从而大大地缩短了S参数的测量过程,节省了大量的测量时间。文中给出测量实例。
-
关键词:
- 微波测量; S参数; 多端口网络
Abstract: Generalized equivalent two-port measurement equations for reciprocal multiport network are presented, and problems using mutual equivalent parameters of the measured network in S-parameter measurements have been solved in this paper. This would shorten greatly measurement procedures for S-parameters and save a lot of measurement time. Experimental ex-ample is given. -
S. Stein, Proc. IRE, 42(1954)3, 599.[2]吴宏雄, 电子科学学刊, 13(1991)6，561-5670.[3]T. Nemoto, D. F. Wait, IEEE Trans. on MTT, MTT-16(1968), 866-873.[4]D. Kajfez, IEEE Trans. on IM, IM-24(1975)1, 4-11.[5]R. W. Beatty, A. C. Macpberson, Froc. IRE, 41(1953)9, 1112-1118.[6]吴宏雄, 郑小健, 潘楚华, 微波学报, 1988年, 第3期, 第1-8页.[7]K. Brantervik, E. L. Kollberg; IEEE Trans. on MTT, MTT-33(1985)7, 563-568.[8][8][9]K. Brantervik, IEEE Trans. on MTT, MTT-33(1985)7, 569-575.[10]G. F. Engen, IEEE Trans. on MTT,MTT-15(1977)12, 1075-1079. -
