W[111]尖端场发射电子枪的工作特性
OPERATING CHARACTERISTICS FOR A FIELD EMISSION GUN WITH W[111] TIP
-
摘要: 本文报道了单晶W[111]尖端的制作,以及由W[111]尖端阴极,第一、二阳极组成的三极场发射电子枪(FEG)的工作特性。实验结果表明,这种FEG在枪室真空为510-7Pa,加速电压在30kV的条件下,其虚源半径为1.6nm;亮度为3.8109A/cm2.sterad;场发射电流为1A时,束流稳定性为5%(10min内)。说明它是一种较理想的点状电子源,在实际应用中具有广泛发展前景。Abstract: The fabrication method of W[111] tip and the operating characteristics ofa field emission gun (PEG) which consists of W[111] tip, first and second anodes are reported. Experimental results show that on condition that the vacuum in the gun chamber is better than 510-7 Pa and acceleration voltage is 30kV, the finite radius of the virtual source of the FEG is 1.6nm, and the brightness of FEG is estimated as 3.8109 A/cm2, sterad; on condition that the field emission current is 1A, the stability of beam current is better than 5% in 10 min. It is able to be used in scanning electron microscopesand electron probe system etc.
-
A. V. Crewe et al., J. Appl. Phys., 39(1968) 13, 5861-5868.[2]A. V. Crewe et al., Science, 168(1970) 39, 1338-1340.[3]A. Tonomura et al., J. Electron Microscopy, 22(1973) 1, 141-146.[4]G. Bining et al., Appl. Phys. Lett., 40(1982) 2, 178-180.[5]G. Bining et al., Phys. Rev. Lett., 49(1982) 1, 57-61.[6]杨德清等,微细加工技术,1988年,第1期,第30-34页.[7]杨德清等,云南大学学报(自然科学版),10(1988)2,167-171.[8]刘学悫,阴极电子学,科学出版社,北京,1980年,第258页.[9]杨德清等,电子科学学刊,12(1990)6,660-6650.[10]杨德清等,微细加工技术,1991年,第1期,第14-19页.[11]陆家和等,表面分析技术,电子工业出版社,北京,1987年,第98页.[12]唐天同,应用带电粒子光学引论,西安交通大学出版社,西安,1986年,第322-324页.[13]唐天同,应用带电粒子光学引论,西安交通大学出版社,西安,1986年,第317页.[14]C. Wiener et al., J. Appl. Phys.,44(1973)5,2140--2148. -
