多输出端电流模式全差分积分器实现带通滤波器的方法及仿真

江金光; 何怡刚

多输出端电流模式全差分积分器实现带通滤波器的方法及仿真

计量
- 文章访问数: 2924
- HTML全文浏览量: 133
- PDF下载量: 906
- 被引次数: 0
出版历程
- 收稿日期: 2002-07-25
- 修回日期: 2002-12-23
- 刊出日期: 2003-12-19

Realization and Simulation of Band-Pass Filter Based on MCDI

摘要

摘要: 该文提出了利用低电压多输出端电流模式全差分积分器(MCDI)设计实现连续时间电流模式滤波器的方法.分析并模拟了MCDI及所提出的滤波器的特性,应用3.3V,0.5m,CMOS工艺参数仿真得到的二阶带通滤波器功耗仅为0.6mW左右,且其中心频率可在很宽的范围内调控.此外,这种滤波器还具有结构简单、对称性好、失真小等优点,适于全集成.
- 全差分式;低电压、低功耗;电流模式积分器;连续时间滤波器
Abstract: A methodology to realize continuous-time current-mode filters using low-voltage Multi-output Current-mode Differential Integrator (MCDI) is presented. At first, the char-acteristics of MCDI and the proposed filters which employ MCDI are analyzed and simu-lated. Simulation results not only predict second-order band-pass filter dissipating as little as 0.6mW power or so with 3.3V power supply using 0.5/xm CMOS technology, while the center frequency of which can be tuning in a wide range, but also with the advantages such as simple structure, good symmetry, low harmonic distortion, and suitable for integration.

HTML全文

参考文献(1)

Lee Sang-soo, Zele R H, Allstot D J. Guojin Liang. A continuous-time current-mode integrator.IEEE Trans. on Circuits and Systems, 1991, 38(10): 1236-1238.[2]Wu J, EI-Marsy E. Current-mode ladder filters using multiple output current conveyors. IEE Proc. Circuits, Devices. Syst. 1996, 143(4): 218-222.[3]Tsividis Y P. Integrated continuous-time filter design-An overview[J].IEEE J. of Solid-State Circuits.1994, 29(3):166-176[4]Lee Sang-soo, Zele R H, Allstot D J, Guojin Liang. CMOS continuous-time current-mode filters for high-frequency applications[J].IEEE J. of Solid-State Circuits.1993, 28(3):323-329[5]Zele R H, Allstot D J, Fiez T S. Fully balanced CMOS current-mode circuits[J].IEEE J. of SolidState Circuits.1993, 28(5):569-575[6]Zele R H, Allstot D J. Low-voltage fully differential switched-current filters[J].IEEE J. of SolidState Circuits.1994, 29(3):203-209[7]Fiez T S, Allstot D J. CMOS switch-current ladder filters[J].IEEE J. of Solid-State Circuits.1990,25(6):1360-1367[8]Khoury J M. Design of a 15-MHz CMOS continuous-time filter with on-chip tuning[J].IEEE J. of Solid-State Circuits.1991, 26(12):1988-1997[9]Un-Ku Moon, Bang-Sup Song. Design of low-distortion 22-kHz fifth-order Bessel filter[J].IEEE J.of Solid-State Circuits.1993, 28(12):1254-1264[10]赵录怀,邱关源.用对数域电流模式积分器实现的高频集成滤波器.电路与系统学报,1996,1(3):32-37.[11]赵录怀,邱关源.一种新型电流模式连续时间波有源滤波器.电子学报,1997,25(4):108-110.[12]赵录怀,邱关源.电流模式高阶滤波器设计的递推方法.电子科学学刊,1997,13(3):424-427.[13]石文孝,韩庆全.基于多输出差动差分电流传送器跳耦结构滤波器.通信学报,2000,21(2):30-35.[14]江金光,何怡刚,吴杰.基于电流传送器的椭圆函数滤波器设计.电路与系统学报,2000,1(5):32-37.[15]何怡刚,江金光,吴杰.通用有源电流模式滤波器.电子学报,1999,27(11):21-23.
