金属栅厚度对介质波导漏波天线辐射特性的影响
EFFECT OF METALLIZATION THICKNESS ON MILLIMETER WAVE LEAKY-WAVE ANTENNAS
-
摘要: 本文研究了厚金属栅加载介质插入波导漏波天线的辐射特性,运用电磁场的网络解析法的推广模型建立起本征值方程。数值结果表明,金属栅厚度对漏波天线波求方向影响较小,但对漏波天线的辐射效率和波束宽度有明显的影响。
-
关键词:
- 漏波天线; 等值电路; 复传播常数
Abstract: The effect of metallization thickness on a leaky wave antenna based on a metal-strip-loaded dielectric insert waveguide is investigated. The intrinsic equation is set up by. the extended version of the network analytical method of electromagnetic field. Numerical results show that the effect of metallization thickness is smaller on the direction of main beam and very noticeable on the beamwidth and aperture efficiency. -
Rlohn R L,et al. IEEE Trans. on AP, 1979, AP-38(10): 764-773.[2]Solbach K. E-band leaky wave antenna using dielectric image line with etched radiating elements, IEEE MTT-S Int. Microwave Symp. Digest, Orlando FL, 1979,[3]pp. 214-216.[4]Mittra R, et al. IEEE Trans. on AP, 1981, AP-29(4): 652-654.[5]Trinh T N. et al. Horn image guiee leaky-wave antenna, IEEE MTT-S Inr. Microwave Symp. Digest. Los Angeles:(1981), 20-22.[6]Encinar J A. IEEE Trans. on AP, 1990, AP-38(9): 1405-1412.[7]Guglielmi M, et al. IEEE Trans. on AP, 1991, AP-39(4): 497-504. -
