用WIP电子枪的小型高重复频率电子束加速器
A COMPACT HIGH REPETITION RATE ELEC- TRON BEAM ACCELERATOR WITH WIP ELECTRON GUN
-
摘要: 本文叙述了所研制的一台小型高重复频率电子束加速器装置。该装置的设计指标为:输出电子束能量:120--150keV;电子束流强:5--50A;脉宽:1s;重复频率:100Hz;电子束截面积:550cm2。本加速器的主体是具有独特优点的WIP电子枪。本文着重分析了这种电子枪的工作原理和物理过程,并给出初步实验结果。
-
关键词:
- 电子束加速器; WIP电子枪; 氦离子源
Abstract: The development of a compact high repetition rate electron beam accelerator is reported. The specifications of the device are output electron energy 120--150keV, beam current 5--50A, pulse duration 1 s, beam cross-section 550cm2 and repetition frequence 100Hz. The key part of the accelerator is a wire-ion-pla-sma (WIP) electron gun of particular advantage. The principle of operation of the WIP electron gun and its physical properties are described. The caculation formula of output parameter is given and preliminary experimental results are presented. -
李悌兴,张奇,等.新型低能电子加速器--WIP电子枪.全国第三届高功率粒子束专业学术交流会论文报告集,I.加速器技术,河北承德:1988,9.5-9.10.[2]Wakalopulos G, Conti D K. Wire-Ion-Plasma(WIP): A Revolutionary New Technology for E-Beam Curing. Paper FC83-628, Proc. of Finishing83 Conl. Cincinnati, OH, USA: October[3]-13, 1983, 6.19-6.36.[4]Clark Jr W M, Dunning G J. IEEE J. of QE, 1978, QE-14(2): 126-129.[5]Wakalopulos G. High Peak Power Pulsed WIP Electron Gun. LLNLUCRL-13950. Livermore, CA: 1978, 1-30.[6]Digache D, Bonnet J, David D. A Short Pulse Secondary Emission Electron Gun for High Pressure Gas Lasers and Plasma Chemical Reactors. in Sixteenth ICPIG. Dusseldorf: 1983, 782-783.[7]McClure G W. Appl. Phys. Lett. 1963, 2(12): 233-234. -
