利用脉间跳频和信号增强技术实现低信噪比下雷达距离超分辨
RANGE SUPER-RESOLUTION AT LOW SNR VIA INTERPULSE FREQUENCY HOPPING AND SIGNAL ENHANCEMENT
-
摘要: 针对大时带积(TB)线性/非线性调频(LFM/NLFM)脉压信号,本文研究了低信噪比(SNR)下获得雷达距离维超分辨性能的技术和方法。首先提出了一种有效的信号增强算法,并通过脉间跳频的设计获得了不同目标回波非相关性,进而提出了一系列进一步降低超分辨处理的SNR门限的有效方法。计算机模拟表明:同样条件下本文方法较直接频域处理使超分辨估计所需的SNR门限改善了10dB以上,较好地解决了低SNR环境下雷达距离域的多目标超分辨问题。Abstract: For linear and non-linear frequency modulation (LFM/NLFM) signals with large time-bandwidth product (TB),radar super-resolution in range domain at low SNR is investigated.A novel signal enhancement algorithm based on FFT for LFM/NLFM signals used for preprocessing,which significantly raises the effective signal-to-noise ratio(SNR),is presented.By use of decorrelation between echoes of different targets achieved by pulse-to-pulse carrier frequency hopping,a vvariety of approaches are suggested to further lower the SNR threshold for range super-resolution.Monte-Carlo simulation results are presented to illustrate the inproved performance.
-
林茂庸,柯有安.雷达信号理论.北京:国防工业出版社.1984,115-151.[2]Krim H, Viberg M. Two decades of array signal processing research. IEEE SP Mag. 1996, 13(4), 67-94.[3]Bruckstein A M, et al. The resolution of overlapping echoes. IEEE Trans. on ASSP, 1985, ASSP-33(6): 1357-1367.[4]Gabriel W F. Superresolution techniques and ISAR imaging. IEEE National Radar Conf，Dallas, Texas: 1989, 48-55.[5]Gabriel W F. Superresolution techniques in range domain. IEEE Int. Radar Conf., Arlington, Virginia: 1990, 263-267.[6]Abatzoglou T J. Superresolution signal processing and its application. Proc. of SPIE, 1995, Vo1.2562,88-98.[7]Cadzow J A. Signal enhancement--A composite property mapping algorithm. IEEE Trans. on ASSP,1988,ASSP-36(1): 49-62.[8]Vax M, Kailath T. Determining the number of signals by information theoretic criteria. IEEE Trans. on ASSP, 1985, ASSP-33(2): 387-392.[9]Karhunen J T, Joutsensalo J. Sinusoidal frequency estimation by signal subspace approximation. IEEE Trans. on SP, 1992, SP-40(12): 2961-2972.[10]Johnson J A, Fairhead A C. Waveform design and Doppler sensitivity analysis for nonlinear FM chirp pulses. IEE Proc-F, 1986, 133(2): 163-175. -
