光控介质谐振器振荡器的实验研究
EXPERIMENTAL STUDY OF AN OPTICALLY CONTROLLED DIELECTRIC RESONATOR OSCILLATOR
-
摘要: 本文报道了关于光控介质谐振器振荡器的实验结果。对一只9.5GHz的介质谐振器振荡器进行实验,用硅半导体光敏材料,入射15mW红光,光控频率调谐达17.5MHz,红光功率的平均频率调谐率为1.17MHz/mW。入射5.5mW紫光,光控频率调谐达到12.3MHz,紫光功率的平均频率调谐率为2.24MHz/mW。在整个调谐范围内振荡器的微波输出功率随光功率增加而略有上升。Abstract: Some new experimental results of optically controlled dielectric resonators (DRO) are presented. A very stable X-band DRO was found to be optically tunable up to 17.5MHz with modulation rate of 1.17MHz/mW with red light illumination. And an even higher modulation rate of 2.24MHz/mW with illumination of violet light was obtained. Instead of a drop in optically controlled DRO output power, a little rise of output power was achieved.
-
Esman R D, et al. IEEE Trans. on MTT, 1989. MTT-37(0):1512-1518.[2]Herczfeld P R, et al. Proc. 14th European Microwave Conf. Liege. Belgium, Sept. 1984, 268-273.[3][3][4]Herczfeld P R, et al. Optically Controlled Microwave Devices and Circuits, 1985 IEEE MTT-S Digest, H-15, 211-214.[5]Herezfeld P R, et al, RCA Rev.,1985, 46(12): 528-551.[6]Xu Deming, et al. A New Method for Analysing the Optically Controlled Dielectric Resonators. Proc. Europ. Microwave Gnnf. hadapest, Hangary. Sept. 1990, 1609-1611.[7]郭开周,等.电子科学学刊,1991, 13(5): 532-537. -
