任意块状介质填充矩形波导色散特性的数值分析
NUMERICAL ANALYSIS OF DISPERSION CHARACTERISTICS OF RECTANGULAR WAVEGUIDES FILLED WITH ARBITRARY BLOCK-SHAPED DIELECTRICS
-
摘要: 本文给出了一个用有限元法计算任意块状介质填充矩形波导的孪生波主模和高次模色散特性的标准程序。使用该程序,对十余种不同结构、不同介质加载矩形波导色散特性的计算,证实了所述程序的可靠性,文中对工字形介质填充波导的有用带宽作了详细的分析。本文所提供的各种色散特性曲线可供分析和设计有关微波元件时参考。
-
关键词:
Abstract: This paper presents a standard program using finite-element method to calculate dispersion characteristics of hybrid dominant and higher order modes in rectangular waveguide filled with arbitrary block-shaped dielectrics. The dispersion characteristics calculated with the program for more than ten different rectangular waveguides loaded with various dielectric distributions verify the reliability of the program. The useful bandwidth of waveguide filled with I-shaped dielectric is analysed in detail. The dispersion curves given in this paper can be used in analysing and designing related microwave components. -
徐善驾,电子科学学刊,5(1983), 6.[2]徐善驾,应用科学学报,2(1983), 39.[4]Chang-Tsuo Liu, et al.,IEEE Trans. on MTT, MTT-29(1981), 805.[5]G. Conzalez, et al.,IEEE Trans. on MTT, MTT-17(1969), 284.[6]T. K. rindakly, et al., IEEE Trans. on MTT, MTT-24(1976), 39.[7]徐善驾,电子学通讯,4(1982), 234.[8]徐善驾,电子学报,10(1982), 39. -
