电流模式CMOS OTA滤波器实现
REALIZATIONS OF CIJRRENT-MODE CMOS OTA FILTERS
-
摘要: 本文提出了利用CMOS OTA综合连续时间电流模式滤波器的方法。应用信号流图模拟,系统地生成了二阶CMOS OTA电流滤波器。分析了OTA的非理想因素对滤波器高频性能的影响,并给出了简单的高频补偿方案。最后,给出了一个四阶巴特沃思低通滤波器的设计实例并经PSPICE仿真证实。Abstract: A methodology to synthesise continous-time current-mode filters using CMOS OTAs is presented. Second-order CMOS-OTA current fllters are systematically generated from the simulation of signal flow graph for a general biquadratic function .The non-ideal effects in high frequency compensation frequency characteristic of OTA-C filters are analyzed. A simple high off frequency method is discussed. Finally, A 4th-order Butterworth lowpasss filter with 1MHz cut and simulated with PSPICE program.
-
Wilson B, et al. Current-mode signal processing circuits, IEEE ISCAS, Helsinki: 1988, Vol. 3:[2]65-2668,[3]Toumazou C,et al. Eds, Current-Mode Analogue Signal Processing, IEE Proc. G., 1990, 137(2): 1-184.[4]Hughes B, et al. Switched-current-A new technique of analogue sampled-data signal processing, IEEE ISCAS, Pritland, 1989, Vol. 3: 1584-1587.[5]吴杰,邱关源.通信学报,1995, 16(1): 56-62.[6]Wu die. Int[J].J. Electronics.1994, 76(6):1115-1120 -
