频率和极化复用的群分波器的准确设计
EXACT DESIGN OF A WIDE-BAND WAVEGUIDE DUPLEXING FILTER
-
摘要: 本文利用等效电路的概念,在求解了波导接头的边界值问题后,给出了4GHz、6GHz频率和极化复用馈线系统中群分波器的准确设计方法。计算结果与实测相符。此方法可用于同类型其它结构的分波器设计。
-
关键词:
Abstract: After solving the boundary value problem of a waveguide junction, the exact design method of a wide-band duplexing filter for 4 and 6 GHz relay communication is obtained by using the concept of equivalent circuit. The theoretical results are in good agreement with the measured data. This design method can be used for other wide-band duplexer with similar construction. -
P. Marie, Onde Electrique, 39(1959), 189-194.[2]K. Schnetzler, Nachrichten Technische Zeitschrift, 22(1969)3, 144-145.[3]加藤修助,研究实用化报告,3(1970), 581-587.[4]小口文一,マイクロ波ぉよびミリ波回路,丸善株式会社,1964.[5]Sharp, IEEE Trans. on MTT, MTT-15(1967), 109-116.[6]G. Simpson, A generalized n-port cascade connection, 1981 Int. Microwave Symposium Digest, pp. 507-510. -
