宽带速调管输出段的时间积分程序
THE TIME INTEGRAL PROGRAM FOR OUTPUT SECTION OF BROADBAND KLYSTRONS
-
摘要: 本文采用一维单周期时间积分模型计算速调管输出段的电子与高频场的能量交换过程,比较简单地解决了距离积分向时间积分的过渡以及输出段中电子圆盘间空间电荷力的计算问题。用DJS-6自动化语言编写了计算程序,用该程序计算了C波段宽带速调管,计算结果与实测值基本一致。利用该程序对输出段的重要参数如阻抗、间隙渡越角等对效率的影响作了研究。
-
关键词:
Abstract: In this paper, we present a single period, one dimensional time integral model, with which we can calculate the energy exchange between the rf field and electrons in the output section of a klystron. We give a method by which the distance integral can be transformed simply into the time integral and the calculation of the space charge force of electron disks in the output section can be resolved.We write a program with DJS-6 type computer automation language, with which we calculate a C-band broadband klystron. It shows that the calculated resultsand the experimental ones are in good agreement. We also study the influence of the parameters of output section on the efficiency of the klystron. -
S. E. Webber, IRE Trans. on ED, ED-5(1958), 206.[2]P. J. Tallerico, IEEE Trans. on ED, ED-18 (1971), 374.[3]J. R. Hechtal, IEEE Trans. on ED, ED-16(1969), 212.[4]电子管设计手册编辑委员会编,大功率速调管设计手册,第二章,国防工业出版社,1979年.[5]J. R. Rowe, Nonlinear Electron-Wave Interaction Phenomena. Academic Press, N. Y. 1965. Chapter V.[6]T.K.Yama et al., IEEE Trans. on ED, ED-24(1977), 3. -
