速调管双间隙输出段的效率计算
EFFICIENCY CALCULATIONS OF RESONANT COUPLED CAVITY OUTPUT SECTION OF BROADBAND KLYSTRONS
-
摘要: 本文在计算速调管双间隙输出段的效率时,不沿用传统的花费时间的电子圆盘时间积分法和过于简单化的空间电荷波法,而提出了一种新的综合性的计算方法。使用这种方法其所需计算时间比电子圆盘法要少得多;计算结果与热测结果基本吻合。
-
关键词:
Abstract: The efficiency of output section of broadband klystron with resonant coupled cavity is calculated. In solving this problem, we use neither the time integrated electron disk model nor the space charge wave theory. The disk model requires too long computer time, and the space charge wave theory is simplistic. We propose a new modified method, with which the computer time is much saved and the calculated result is in fair coincidence with the measured one. -
M. Chodorow and J. Wessel-Berg, IRE Trans. on ED, ED-8(1961),44.[2]H. Golde, IRE Trans. on ED, ED-8(1961), 192.[3]D. H. Preist and W. J. Leidigh, IEEE Trans. on ED, ED-10(1963), 201.[4]D. H. Preist and W. J. Leidigh, IEEE Trans. on ED, ED-11(1964), 169.[6]M. J. Smith, Vacuum, 30(1980), 455. -
