有限宽边缘槽波导分析
ANALYSIS OF GROOVE WAVE GUIDE WITH FINITE WIDTH FRINGE
-
摘要: 本文在运用Babinet原理分析边缘等效电路的基础上根据横向谐振关系建立色散方程。首次获得了由于辐射引起的衰减常数;解释了漏波场。所得结果与实验吻合较好。Abstract: According to the transverse resonance method the dispersion relation is derived based on the analysis of fringe equivalent circuit by using Babinet principle. The attenuation constant causing by radiation is obtained. The explanation of the leakage waves is-given. The theoretical results agree with the experimental ones.
-
H. M, Altsthuler, et al., IRE Trans. on MTT-7(1985), 213-221.[2]A. A. Oliner, et al., IEEE Trans. on MTT,MTT-33(1985), 755-764.[3]N. Marcuvitz, Waveguide Handbook, New York, McGraw-Hill Co., 1951, p. 186.[4]A. A..Oliner, et al., Int. Microwave .Symp. Digest, Boston. USA, 1983, p. 390-392. -
