有耗介质覆盖平面导体表面波传播特性的计算
PROPAGATION PROPERTY OF THE SURFACE WAVE ON CONDUCTOR-BACKED LOSSY DIELECTRIC PLANE
-
摘要: 本文推导了圆柱坐标系下有耗介质涂覆平面导体表面波的场函数和本征方程、每波长径向衰减常数;分析了介质特性参数、介质层厚度与的关系;指出磁损耗介质比电损耗介质有更好的抑制表面波的效果。
-
关键词:
- 有耗介质; 表面波; 径向衰减常数
Abstract: The eignvalue equation, the attenuation constant a and the field distribution function of the surface wave(SW) in a conductor-backed lossy dielectric layer are derived. The relationship between the a and the parameters of the dielectric material is described. It was found that the magnetic-loss material showed better performance than the electric-loss material in attenuating the SW. -
Barlow M, Cullen A L. Proc. IEE, part Ⅲ, 1953, 100: 321.[2]饶克谨,等.吸收表面波的薄涂层材料的性质.吸收剂评价方法专题研讨会,北京,1991.[3]Collin R E著,侯元庆泽.导波场论.上海科学技术出版社,1966年,446-450.[4]时振栋,等.有耗介质涂覆导体平面上的表而波分析.1991年全国微波会议论文集,西安,1991,244-248.[5]克拉特 F,等著,阮颖铮,等译.雷达散射截面.北京:电子工业出版社,1988,263. -
