非晶硅液晶光阀的研制
RESEARCH ON LIQUID CRYSTAL LIGHT VALVE WITH AMORPHOUS SILICON
-
摘要: 用惰性小而廉价的a-Si:H膜作液晶光阀的光导层是一种理想选择。采用阻抗匹配的方法,设计和制作了a-Si:H液晶光阀。在大屏幕投影系统上获得了清晰的投影图象,分辨率为201p/mm。光阀感光度测量表明,写入光在100w,cm2以下,读出光随写入光线性变化。在写入光为100w/cm2时,瞬态响应测量结果为:上升时间60ms,下降时间80ms。
-
关键词:
- 液晶光阀; 阻抗匹配; 大屏幕投影
Abstract: It is an ideal selection to use a-Si:H film, which is cheap and with small lag, as the photoconductive layer of liquid crystal light valve. By using the method of impedance matching, an a-Si:H liquid crystal light valve is designed and fabricated, and the clear image on a large screen projective system is obtained. The resolution of the valve is 201p/mm. The sensitometry measurement shows that the projection light level varies linearly with the writing light level when the latter is below 100W/cm2. The measurement of transient response at the writing light level of 100W/cm2 indicates that the rise time is 60ms and the decay time is 80ms. -
Beard T, et al. Appl. Phys. Lett. 1973,22(3): 90-92.[2]Bleha W. Laser Focus, 1993, 19(10): 111-120.[3]Efrom U,et al. J. Appl. Phys.,1985, 57(4): 1356-1368.[4]陈刚,海宇涵等,反射式非晶硅液晶光阀.液晶发现百周年纪念会议论文集,北京:1988,16-17.[5]陈刚.实时快速非晶硅液晶光阀及快速混合相变液晶研究:[硕士论文].北京:中国科学院电子学研究所,1988年.[6]海宇涵,陈刚.红外,1989, (11):封底.[7]海宇涵,等.非晶硅液晶光阀的结构设计和初步研究:第六届全国非晶态材料和物理学术讨论会文集,佳林: 1991,113-114.[8]海宇涵,等.非晶硅液晶光阀的阻抗匹配.第六届全国液晶会议论文集.深圳: 1991,7.[9]海宇涵,等.电子科学学刊,1988,10(6): 528-535.[10]林璇美,等.用常规PECVD方法高速沉识a-Si : H膜.第六届全国非晶态材料和物理学术讨论会文集,桂林:1991, 16-17. -
