带平台多阶振幅量化的低副瓣口径分布
LOW SIDELOBE APERTURE DISTRIBUTION OF MULTI-STEP AMPLITUDE QUANTIZATION WITH PEDESTAL
-
摘要: 本文提出了一种带平台多阶振幅量化的低副瓣口径设计方法并论述了其分析方法和计算公式,给出了本文算法与作者(1993)提出的多阶振幅量化方法在峰值副瓣电平、口径效率、归一化输入功率以及具有容差情况下的副瓣恶化等的计算比较结果。结果表明,在相同的条件下,本文提出的方法优于多阶振幅量化方法。Abstract: A low sidelobe aperture designing method of multi-step amplitude quantization with pedestal is proposed, and general analysis and formulas are described. The computation results compared with author s(1993) previous method Multi-Step Amplitude Quantization (MSAQ) on peak sidelobe level, aperture efficiency, normalized input power and sidelobe degradation with tolerance are given. It is shown that, in the same conditions, the method presented in this paper is better than the MSAQ.
-
Skolnik M. IEEE Trans. on AP, 1964, AP-12(7):408-417.[2]Goo Y C. IEE Proc. -H, 1983, 130(5): 343-351.[3]Guo Y C. IEE Proc.-H, 1983, 130(5):352-357.[4]Guo Y C. The amplitude quantization of density-weighted phased array antenna. Proc. of 1985[5]Int. Symp. on Antenna and EM Theory. Beijing: 1985, 667-671.[6]陈红,等.武汉大学学报(电波传播专刊),1991,167-171.[7]Guo Y C. Analysis and computation of circular aperture arrays with multi-step amplitude quantization, 1992 IEEE AP-S Int. Symp. and URSI Radio Science Meeting. Chicago: 1992, 473-[8]476.[9]Lee J J. IEEE Trans. on AP, 1988, AP-36(3):339-344.[10]Gao Tie, Design of AEW 2-D Solid-State Active Phased Array Antennas with Low SideIobe[11]Level. The Third International Symposium on Antenna and EM Theory. Nanjing: 1993, 545-548.[12]高铁,李建新.中国空间科学技术,1993,13(3): 34-42.[13]李建新,高铁.现代雷达,1992,14(6): 37-44.[14]Li J X, Gao T. Pattern Statistic Characteristic Research for Low Sidelobe Solid-State Active Phase Array Antenna. 1993 Asia-Pacific Microwave Conference. Taiwan: 1993, 21-24. -
