一种应用于GNSS接收机的新型低功耗高速预分频

于云丰; 马成炎; 叶甜春

doi:10.3724/SP.J.1146.2009.00842

一种应用于GNSS接收机的新型低功耗高速预分频

doi: 10.3724/SP.J.1146.2009.00842

于云丰^{①;马成炎,},
马成炎,
叶甜春

计量
- 文章访问数: 3247
- HTML全文浏览量: 127
- PDF下载量: 774
- 被引次数: 0
出版历程
- 收稿日期: 2009-06-03
- 修回日期: 2010-01-18
- 刊出日期: 2010-07-19

A New Low-Power High-Speed Prescaler in GNSS Receivers

Yu Yun-feng^{①;马成炎
,},
Ma Cheng-yan,
Ye Tian-chun

摘要

摘要: 该文设计了一款应用于全球卫星导航系统(GNSS)接收机射频芯片的基于新型源耦合锁存器结构的预分频，用于产生接收机所需要的本振信号。与传统的静态源耦合逻辑锁存器相比，新结构引入一个钟控晶体管，可实现在采样期间减小锁存器的时间常数，有效地提高了最高工作频率，并且扩展了工作频率范围。通过建立一个简单但有效的小信号模型，新结构的优点被详细阐述。实验结果显示，该预分频最高频率可达6.9 GHz，消耗电流仅为1.2 mA。该预分频在0.18 m CMOS工艺上实现，已成功应用于GNSS接收机射频芯片中。
- 全球卫星导航系统; 源耦合逻辑; 预分频; 本振
Abstract: A new prescaler based on new Source Coupled Logic(SCL) latch is proposed in this paper, supplying Local Oscillator (LO) for receivers. Compared to traditional static SCL latch, a clock-controlling transistor is added to reduce the time constant at sensing time, and as a result, the maximum operating frequency increases and the operating range is enlarged. A simple but to some extent accurate small signal model for this new architecture is developed, and the advantages of new design are described in detail. This prescalers maximum operating frequency can reach to 6.9 GHz when its current is only 1.2 mA. The prescaler is manufactured in 0.18 m CMOS process, and it has been successfully applied to GPS receivers.

HTML全文

参考文献(1)

[1] Henzler S and Koeppe S. Design and application of power optimized high-speed CMOS frequency dividers[J].IEEE Transactions on Very Large Scale Integration (VLSI) Systems.2008, 16(11):1513-1520 [2] Kim D D, Cho Choong-yeun, and Kim Jong-hae. Scalable statistical measurement and estimation of a mmwave CML static divider sensitivity in 65nm SOI CMOS[C]. 2008 IEEE Radio Frequency Integrated Circuits Symposium, Atlanta, Georgia, June 15-17, 2008: 625-628. [3] Park D M and Cho S H. A 18 V 900 W 4.5 GHz VCO and prescaler in 0.18 m CMOS using charge-recycling technique[J].. IEEE MicroWave and Wireless Components Letters.2009, 19(2):104-106 [4] Jang Sheng-Lyang, Lin Chi-Wen, and Liu Cheng-Chen, et al.. An active-inductor injection locked frequency divider with variable division ratio[J].IEEE MicroWave and Wireless Components Letters.2009, 19(1):39-41 [5] Mohanavelu R and Heydari P. A novel 40-GHz flip-flop-based frequency divider in 0.18m CMOS[C]. 31st European Solid-State Circuits Conference(ESSCIRC 2005), Grenoble, France, Sept. 12-16, 2005: 185-188. [6] Farazian M, Gudem P S, and Larson L E. A CMOS multi-phase injection-locked frequency divider for V-band operation[J].IEEE Microwave and Wireless Components Letters.2009, 19(4):239-241 [7] Mo Yuan, Skafidas E, and Evans R, et al.. Analysis and design of a 50-GHz 2:1 CMOS CML static frequency divider based on LC-tank[C]. European Microwave Integrated Circuit Conference, Amsterdam, Netherlands, Oct. 27-28, 2008: 64-67. [8] Razavi B, Lee K F, and Yan R H. A 13.4-GHz CMOS frequency divider[C]. IEEE International Solid-State Circuits Conference, San Francisco, CA, USA, Feb. 16-18, 1994: 176-177. [9] Wang Hong-mo. A 1.8V 3mW 16.8GHz frequency divider in 0.25m CMOS[C]. IEEE International Solid-state circuits Conference, San Francisco, CA, USA, Feb.7-9, 2000: 196-197. [10] Wong M C, Cheung S L, Luong H C. A 1-V 25-mW 5.2-GHz frequency divider in a 0.35-m CMOS process[J].. IEEE Journal of Solid-State Circuits.2003, 38(10):1643-1648 [11] Shinmyo A, Hashimoto M, and Onodera H. Design and optimization of CMOS current mode logic dividers[C]. IEEE Asia-Pacific Conference on Advanced System Integrated Circuits (AP-ASIC2004), Fukuoka, Japan, Aug. 4-5, 2004: 434-435. [12] Singh U and Green M. Dynamics of high-frequency CMOS dividers[C]. 2002 IEEE International Symposium on Circuits and Systems, Scottsdale, Arizona, USA, May 26-29, 2002: 421-424. [13] Lu Jian-hua, Wang Zhi-gong, and Tian Lei, et al.. An 8.5GHz 1:8 frequency divider in 0.35m CMOS technology[J]. Chinese Journal of Semiconductors, 2003, 24(4): 366-369.
