3-节滤波器型-模双间隙腔加载同轴-矩形波导输出电路研究

林福民

doi:10.3724/SP.J.1146.2007.00703

3-节滤波器型-模双间隙腔加载同轴-矩形波导输出电路研究

doi: 10.3724/SP.J.1146.2007.00703

林福民

基金项目:

广东省自然科学基金(04300742)资助课题

计量
- 文章访问数: 3607
- HTML全文浏览量: 118
- PDF下载量: 806
- 被引次数: 0
出版历程
- 收稿日期: 2007-05-10
- 修回日期: 2007-12-31
- 刊出日期: 2008-11-19

Research on 3-Stage Filter Type of Output Circuit of -Mde Duble-gap Cvity Laded by Coaxial-Rectangular Waveguide

Lin Fu-min

摘要

摘要: 该文提出了一种适合于低频段中等功率的宽带速调管的新型3-节滤波器型输出电路-模双间隙腔加载同轴-矩形波导输出电路，并对输出电路的性能以及各部分结构对输出腔间隙阻抗的影响规律进行详细研究。研究结果表明，同轴-矩形波导混合型输出电路不仅克服了低频段宽带速调管中输出波导尺寸太大而影响聚焦系统的困难，有利于提高电子注通过率和整管效率，同时还具有很好的输出带宽潜力和良好的高功率承受能力。
- 宽带速调管 /
- 输出电路 /
- 同轴-矩形波导转换 /
- 双间隙腔 /
- 滤波器
Abstract: A new kind of 3-stage filter type of output circuit for lower RF band and middle power broadband klystron, -mode double-gap cavity loaded by Coaxial-Rectangular Waveguide output circuit, is put forward and the feasibility is demonstrated. The performance of this kind of output circuit is simulated and the influence of all parts of the output circuit on the gap impedance of the output cavity is investigated in detail. The research results show that, the coaxial-rectangular waveguide output circuit not only overcomes the obstacle of big rectangular waveguides impairment of focus system of beams and is of benefit to raising the efficiency, but also has a very wide band and high power capacity.
- B /
- r /
- o /
- a

HTML全文

参考文献(1)

[1] Gelvich E A, and Zhery E V, et al.. A new generation ofpower klystrons on the base of multiple-beam design. IEEEMTT-S, Digest, 1991: 1319-1329. [2] Gelvich E A, and Borisov L M, et al.. The new generation ofhigh-power multiple-beam klystrons, IEEE Trans[J].on MTT.1993, 41(1):15-19 [3] Pobedonostsev A S and Gelvich E A. Multiple-beammicrowave tubes. IEEE MIT-S Digest, 1993: 1131-1134. [4] 丁耀根, 彭钧. 多注速调管一种新型大功率微波放大器.电子科学学刊, 1996, 18(1): 64-71. [5] Ding Yaogen, Shen Bin, Shi Shaomin, and Cao Jin. S-bandmultibeam klystron with bandwidth of 10%[J].IEEE Trans. onof Electron Devices.2005, 52(5):889-894 [6] Ding Yaogen, Zhu Yunshu, and Yin Xiulin, et al.. Researchprogress on L-Band 100kW CW broadband multi-beamklystron. Proceedings of Sixth International VacuumElectronics Conference, Huis ter Duin, Noordwijk, theNetherland, 2005: 261-262. [7] 林福民, 丁耀根. L 波段多注速调管同轴线滤波器宽带输出回路的研究和设计[J].电子与信息学报.2004, 26(5):813-819浏览 [8] 林福民, 关天浩. 门钮式同轴TEM-矩形TE10 微反射过度结构. 真空电子技术, (录用). [9] 林福民, 丁耀根, 沈斌. 强耦合双间隙微波谐振腔的特性分析[J].电子与信息学报.2003, 25(7):982-989浏览 [10] 林福民，丁耀根. 适合于低波段宽带多注速调管的四耦合槽模强耦合双间隙输出腔的设计和讨论. 真空电子技术, 2003, 5:39-41. [11] 林福民, 丁耀根, 刘铁山, 孙小欣. 宽带速调管滤波器加载输出腔间隙阻抗的频率特性的模拟计算方法[J].电子与信息学报.2003, 25(12):1688-1694浏览 [12] 林福民, 丁耀根, 张志强, 黄云平. 速调管双间隙腔的间隙阻抗矩阵频率特性的模拟计算方法[J].电子与信息学报.2004,26(9):1480-1486浏览 [13] 丁耀根, 朱允淑. 宽带速调管滤波器型输出回路设计方法的修正和间隙作用阻抗的计算.电子学通讯, 1982, 4(6): 354-364.
