基于HQBA的平移不变双基地SAR成像
doi: 10.3724/SP.J.1146.2008.00777
Image Formation of Translational-Invariant Bistatic SAR Based on HQBA
-
摘要: 该文使用HQBA(Half Quasi-Bistatic Angle)的概念和驻定相位原理，推导平移不变双基地SAR点目标回波信号的二维精确频谱，深入分析频谱中各相位项的物理意义，提出基于HQBA计算的RD成像处理流程，并对平移不变双基地SAR的HQBA，RCM和成像效果进行仿真。结果表明，该方法能有效校正平移不变双基地SAR的距离单元徙动，提高成像质量。Abstract: By the method of stationary phase and the concept of HQBA (Half Quasi-Bistatic Angle), an exact two-dimensional spectrum of translational-invariant bistatic SAR is derived in this paper. Based on the analysis of every exponential term in the expanded spectrum, a flow chart of Range-Doppler algorithm with the computation of HQBA is proposed. Simulation results of HQBA, RCM and focused points are also provided. As they show, the proposed method can correct the RCM accurately, and improve the imaging quality.
-
Krieger G and Moreira A. Spaceborne bi- and multistaticSAR: potentials and challenges[J].IEE Proc.-Radar SonarNavig.2006, 153(3):184-198[2]Geng Xupu, Yan Honghui, and Wang Yanfei. Atwo-dimensional spectrum model for general bistatic SAR[J].IEEE Trans. on Geosci. Remote Sens.2008, 46(8):2216-2223[3]闫鸿慧, 王岩飞, 于海锋等. 一种基于距离补偿的分布式小卫星双基SAR 成像方法[J].电子与信息学报.2005, 27(5):771-774浏览[4]Loffeld O, Nies H, and Peters V, et al.. Models and usefulrelations for bistatic SAR processing[J].IEEE Trans. on Geosci.Remote Sens.2004, 42(10):2031-2038[5]Neo Y L, Wong F, and Cumming I G. A two-dimensionalspectrum for bistatic SAR processing using series reversion[J].IEEE Letters Geosci. Remote Sens.2007, 4(1):93-96[6]Zhang Zhenhua, Xing Mendao, and Ding Jinshan, et al..Focusing parallel bistatic SAR data using the analytictransfer function in Wavenumber domain[J].IEEE Trans. onGeosci. Remote Sens.2007, 45(11):3633-3645[7]Abell M L and Braselton J P. The Mathematic Handbook.Academic Press, 1993.[8]Bamler R. A comparison of range-Doppler and wavenumberdomain SAR focusing algorithm[J].IEEE Trans. on Geosci.Remote Sens.1992, 30(4):706-716[9]Raney R K, Runge H, and Bamler R, et al.. Precision SARprocessing using chirp scaling[J].IEEE Trans. on Geosci.Remote Sens.1994, 32(4):786-799[10]Cafforio C, Pratic C, and Rocca F. SAR data focusing usingseismic migration techniques[J].IEEE Trans. on Aerosp.Electron. System.1991, 27(2):194-207 -
