一种基于PPM的LDPC编译码方案
doi: 10.3724/SP.J.1146.2007.00693
An Encoding and Decoding Scheme of LDPC Codes Based on Pulse Position Modulation
-
摘要: 该文基于LDPC码和PPM调制方式构造了一种适用于UWB无线通信系统的低码率的编译码方案LDPC-PPM。本方案在保证系统性能的前提下，通过改变编码比特到调制符号的映射方式，不但避免了一般编码调制系统中译码和解调之间的迭代运算，而且可以应用快速Hadamard变换(FHT)和基于FHT的后验概率译码(APP-FHT)来进一步降低接收端的译码复杂度。可以证明，该方案等价于BPSK调制下的低码率的LDPC-Hadamard码。仿真结果表明，在信息比特长度是65536，该方案可以在-1.18dB处达到误比特率为 的性能，仅比采用BPSK调制的Turbo-Hadamard码差0.02dB。Abstract: In this paper, a low-rate LDPC-PPM scheme is bring forward which can be applied into UWB communication systems. This scheme can provide good performance with low decoding complexity. By changing the mapping style from coded bits to modulated symbols, not only the iterative operations between decoding and demodulation can be avoided, but also Fast Hadamard Transformation (FHT) and the so called A Posteriori Probability FHT (APP-FHT) algorithm can be adopted to further decrease decoding complexity. It can be proved that this scheme is equivalent to low-rate LDPC-Hadamard codes with BPSK modulation. Simulation results show that this scheme can achieve -1.18dB at bit error rate with data length 65536, which is only worse 0.02dB than Turbo-Hadamard codes with BPSK modulation.
-
[1] Komulainen P and Pehkonen K. Performance evaluation ofsuper-orthogonal turbo codes in AWGN and flat Raleighfading channel[J].IEEE J. Select. Areas Commun.1998, 16(2):196-205 [2] Li Ping, Leung W K, and Wu K Y. Low-rateturbo-Hadamard codes[J].IEEE Trans. on Inform. Theory.2003, 49(12):3213-3224 [3] Yue Guosen, Li Ping, and Wang Xiaodong. Low-rategeneralized low-density parity-check codes with Hadamardconstraints. Proc. IEEE Int. Symp. Inform. Theory (ISIT),Australia, 2005: 1377-1381. [4] Yue Guosen, Li Ping, and Wang Xiaodong. Generalizedlow-density parity-check codes based on Hadamardconstraints[J].IEEE Trans. on Inform. Theory.2007, 53(3):1058-1079 [5] Zhang Hao and Gulliver T Aaron. Bi-orthogonal pulseposition modulation for time-hopping multiple access UWBcommunications[J].IEEE Trans. on Wireless Commun.2005,4(3):1154-1162 [6] Wilson Stephen G. Digital Modulation and Coding. Prentice-Hall, Inc., 1996, Section 3.3. [7] Lentmaier L and Ziganggirov K. Iterative decoding ofgeneralized low-density parity-check codes. Proc. IEEE Int.Symp. Inform. Theory (ISIT), Cambridge, 1999: 149. [8] Lentmaier M and Zigangirov K Sh. On generalizedlow-density parity-check codes based on hamming componentcodes[J].IEEE Commun. Lett.1999, 3(8):248-250 [9] Mckay D J C and Neal R M. Near Shannon limit performanceof low-density parity check codes[J].IEE Electron. Lett.1997,33(6):457-458 [10] Li Ping, Leung W K, and Phamdo Nam. Low density paritycheck codes with semi-random parity check matrix[J].IEEElectron. Lett.1999, 35(1):38-39 -
