适用于移动通信的宽频带微带天线
doi: 10.3724/SP.J.1146.2006.00547
Broadband Microstrip Antennas Suitable for Mobile Communication System
-
摘要: 该文研究新型的宽频带微带天线，采用一种具有双层贴片结构的微带天线的形式，并用在探针顶端加电容性金属圆片来抵消探针感性的方法，增加了天线的工作带宽。制作适用于第二代和第三代移动通信的宽频带微带天线，测试结果显示天线具有良好的带宽特性，能够满足移动通信系统对天线的带宽要求。
-
关键词:
- 移动通信;宽带天线;微带天线
Abstract: A novel broadband microstrip antenna is presented. Double patch configuration is employed, and a circular metal is introduced on the top of the feed probe to counteract the inductance of the probe. As a result, the bandwidth of microstrip antenna is increased. Broadband microstrip antennas suitable for second generation and third generation mobile communication are fabricated, whose measurement results show that good bandwith characteristics are obtained, which can address the need of bandwidth for the mobile communication system. -
Kumar G and Gupta K. Nonradiating edges and four edges gap-coupled multiple resonator broad-band microstrip antennas[J].IEEE Trans. on Antennas on Propagation.1985, 33(2):173-178[2]Wu C K and Wong K L. Broadband microstrip antenna with directly coupled and gap-coupled parasitic patches. Microwave Opt. Technol. Lett. [J], 1999, 22(5): 348-349.[3]Chen Z N and Chia M Y W. Design of broadband probe-fed plate antenna with stub[J].IEE Proc-Microw. Antennas and Propag.2001, 148(4):221-226[4]Pues H F A and Capelle Van de. An impedance-matching technique for increasing the bandwidth of microstrip antennas [J]. IEEE Trans. on AP, 1989, 37(11): 1345-1354.[5]Sze Jia-Yi and Wong Kin-Lu. Slotted rectangular microstrip antenna for bandwidth enhancement[J].IEEE Trans. on Antenna Propagation.2000, 48(8):1149-1152[6]Huynh T and Lee K F. Single-layer single-patch wideband microstrip antenna[J].Electron. Lett.1995, 31(16):1310-[7]Yang Fan, Zhang Xue-Xia, Ye Xiaoning, and Yahya Rahmat-Samii. Wide-band E-shaped patch antennas for wireless communications[J]. IEEE Trans. AP, 2001, 49(7): 1094-1100.[8]Mak C L, Luk K M, Lee K F, and Chow Y L. Experimental study of a microstrip patch antenna with an L-shaped probe[J].IEEE Trans. on Antennas and Propagation.2000, 48(5):777-783[9]Mark C L, Lee K F, and Luk K M. Broadband patch antenna with a T-shaped probe[J].IEE Proc. Microwave Antennas Propagat.2000, 147(2):73-76[10]Vandenbosch G A E. Study of the capacitively fed microstrip antenna element[J].IEEE Trans. on Antennas and Propagation.1994, 42(12):1648-652[11]Xu Xiaowen，Xu Jian， Liu Zhangfa，Zhu Bocheng，and Li Shizhi. Analysis and design of broadband stacked microstrip patch antennas[J]. Journal of Beijing Institute of Technology， 1997, 6(4): 357-362.[12]Liu Zhang-Fa, Kooi Pang-Shyan, and Li Le-Wei, et al.. A method for designing broad-band microstrip antennas in multilayered planar structures[J].IEEE Trans. on Antenna Propagation.1999, 47(9):1416-11420 -
