基于水平集方法的多源遥感数据融合及城区道路提取

曹广真; 金亚秋

doi:10.3724/SP.J.1146.2005.01682

基于水平集方法的多源遥感数据融合及城区道路提取

doi: 10.3724/SP.J.1146.2005.01682

基金项目:

国家重点基础研究项目(2001CB309400)和国家自然科学基金(60571050)资助课题

计量
- 文章访问数: 3628
- HTML全文浏览量: 64
- PDF下载量: 1620
- 被引次数: 0
出版历程
- 收稿日期: 2005-12-26
- 修回日期: 2006-07-06
- 刊出日期: 2007-06-19

Data Fusion of Multi-source Remote Sensing Based on Level Set Method and Application to Urban Road Extraction

摘要

摘要: 该文发展了一种将多光谱遥感图像和雷达遥感图像进行特征融合，实现城区道路半自动提取的方法。通过水平集(Level Set, LS)快速行进 (Fast Marching, FM) 算法中的速度函数，将道路在多光谱图像中的光谱和纹理特征与其在雷达图像中后向散射和空间自相关尺度相结合。雷达图像中的道路信息弥补了多光谱图像中城市道路受高大建筑物、植被等地物阴影的覆盖而使图像容易断裂的缺点，而多光谱图像的道路信息则有助于降低雷达图像中噪声的干扰以及线性水体与道路的混淆。该文方法分别用于上海市不同区域、不同分辨率、不同极化方式的卫星遥感雷达图像(ERS-2, Radarsat-1 SAR)与陆地卫星多光谱图像(Landsat ETM+)的融合，进行道路信息的提取，取得了较好的效果。
- 多光谱图像;雷达图像;水平集方法;道路提取
Abstract: Using data fusion of multi-spectral and microwave radar images, a semiautomatic method is developed based on the level set method for application to urban road extraction. The fast marching method of level set makes data fusion. Radar remote sensing image can make up road breaks due to shadowing of high building or tree canopy in multi-spectral image, while multi-spectral image can be of helpful to decrease speckels and identify linear road from flat water surface. As example, the data fusion and road extraction from the ERS-2 SAR image and Landsat ETM+, as well as RASARSAT-1 SAR image and Landsat ETM+, in Shanghai area are applied.

HTML全文

参考文献(1)

Shackelford K and Davis C H. Urban road network extraction from high-resolution multispectral data. 2nd GRSSISPRS Joint Workshop on Data Fusion and Remote Sensing over Urban Areas, Berlin, Germany, 2003: 142-146.[2]Bessettes V and Desachy J. Using directional variance for urban area analysis on Spot 5 panchromatic images. Proceedings of SPIE on Image and Signal Processing for Remote Sensing VII, Toulouse, 2001, vol. 4541: 288-296.[3]Yan D M and Zhao Z G. Road detection from quickbird fused image using IHS transform and morphology. Proceedings of Geoscience and Remote Sensing Symposium, Toulouse, France, 2003, 6: 3967-3969.[4]Shi W Z and Zhu C Q. The line segment match method for extracting road network from high-resolution satellite images[J].IEEE Trans. on Geoscience and Remote Sensing.2002, 40(2):511-514[5]Katartzis A, Pizurica V, and Sahli H. Application of mathematical morphology and Markov random field theory to the automatic extraction of linear features in airborne images. Proceedings International Symposium on: Mathematical Morphology and Its Applications to Image and Signal Processing, Xerox PARC, Palo Alto, California, 2000: 405-414.[6]Taniguchi R and Kawaguchi E. Road network extraction from Landsat TM image. Third International Conference on Image Processing and Its Applications, Warwick, UK, 1989: 222-226.[7]Jeon B K, Jang J H, and Hong K S. Road detection in spaceborne SAR images using a genetic algorithm[J].IEEE Trans. on Geoscience and Remote Sensing.2002, 40(1):22-29[8]Tupin F, Maitre H, Mangin J F, Nicolas J M, and Pechersky E. Detection of linear features in SAR images: Application to road network extraction[J].IEEE Trans. on Geoscience and Remote Sensing.1998, 36(2):434-453[9]Sethian J A. Level Set Methods and Fast Marching Methods. Cambridge: Cambridge University Press, 1999: 3-76.[10]Sethian J A. A fast marching level set method for monotonically advancing fronts[J].Proceedings of the National Academy of Sciences of the United States of America.1996, 93(4):1591-1595[11]Sethian J A. A Review of the Theory, Algorithms, and Applications of Level Set Methods for Propagating Interfaces. Acta Numerica, Cambridge University Press, 1996, 487-499.[12]Rouy E and Tourin A. A viscosity solutions approach to shape-from-shading[J].SIAM Journal on Numerical Analysis.1992, 29(3):867-884[13]Caselles V, Kimmer R, and Sapiro G. Geodesic active contours[J].International Journal of Computer Vision.1997, 22(1):61-79[14]Haralick R M, Shanmugan K, and Dinstein I. Textural features for image classification[J].IEEE Trans. on Systems, Man, and Cybernetics.1973, 3(6):610-621[15]Anys H, Bannari A, He D C, and Morin D. Texture analysis for the mapping of urban areas using airborne MEIS-II images. Proceedings of the First International Airborne Remote Sensing Conference and Exhibition, Strasbourg, France, 1994, vol.3: 231-245.[16]颜锋华，金亚秋. 尺度分布的Getis统计对遥感图像特征参量空间自相关性的研究. 中国图像图形学报, 2006, 11(2): 191-196.[17]Jin Y Q. Theory and Approach of Information Retrievals from Electromagnetic Scattering and Remote Sensing. Germany: Springer, 2005, Chapter 3.[18]Telea A. An image inpainting technique based on the fast marching method. Journal of Graphics Tools, 2004, 9(1): 25-36.
