应用FDTD/MP方法计算波导加载谐振器的复谐振频率
COMPUTATION OF THE COMPLEX RESONANT FREQUENCY OF WAVEGUIDE LOADED CAVITIES USING FDTD COUPLED WITH MATRIX PENCIL METHOD
-
摘要: 应用FDTD结合MP的方法计算了波导加载谐振器的谐振频率和品质因数。与FDTD/DFT方法比较,这种方法减少了对FDTD运行时间的需求,并且提高了数值精度。与FDTD/Prony方法比较,其优点是计算效率高,对噪声的敏感小。文中以计算实例说明了算法的有效性。Abstract: FDTD coupled with Matrix Pencil method was applied for computation of the resonant frequency and external quality factor of waveguide loaded cavities. With the new method, the computing time is reduced considerably and the accuracy of numerical results are improved compared to the combined approach of FDTD and DFT. Compared with conventional used Prony s method, the advantages of MP technique are its more computational efficiency and less sensitivity to noise. Numerical results of a 3-D rectangular cavity are given for verification of the method.
-
Tatsuya K. A simple method using MAFIA to calculate external Q values of waveguide-loaded cavities, KEK report 89-4, June 1989.[2]Norman M K, Yu D U L. Computer determination of the external (a and resonant frequency of waveguide loaded cavities, Particle Accelerators, 1990, 34(5): 231-250.[3]Jifu Ma, Yaogen Ding, Wenmiao Song. Characterizing waveguide loaded cavities using finite-[4]difference time-domain method, in Proc. of 1997 Asia Pacific Microwave Conference, HongKong: 1997, (1): 825-828.[5]Pereda J A, Vielva L A, et al. Computation of resonant frequencies and quality factors of open dielectric resonators by a combination of the FDTD and Pronys method, IEEE Microwave Guided Wave Lett., 1992, 2(2): 431-433.[6]Ritter J, Arndt F. Efficient FDTD/Matrix-Pencil method for the full-wave scattering parameter[7]analysis of waveguiding structures, IEEE Trans. Microwave Theory Tech., 1996, 44(8): 2450-2456.[8]Hua Y, Sarkar T K. Matrix pencil method for estimating parameters of exponentially damped/undamped sinusoids in noise, IEEE Trans. on ASSP, 1990, ASSP-38(6): 814-824.[9]Berenger J P. A perfectly matched layer for the absorption of electromagnetic waves, J[J].Compu. Phy.1994, 114(1):185-200 -
